168-3604 BARRING & MOUNTING GP (CHG -00 THRU -04)460V/3PH/60HZ

Group No: 168-3604
Part NumberPart NameQty
18013791 BRACKET AS1
0S15952 BOLT (1/2-13X1.25-IN)4
5P82453 WASHER-HARD (13.5X25.5X3-MM THK)4
9M19744 WASHER-HARD (8.8X16X2-MM THK)13
0L13515 BOLT (3/8-16X0.875-IN)2
14819546 GUARD1
5P05377 WASHER-HARD (7.2X14.5X2-MM THK)2
9S87508 NUT-FULL (1/4-20-THD)2
14143189 ADAPTER1
092839910 KEY-SQUARE1
148196911 BRACKET AS1
141431212 GUARD1
1B279013 BOLT (5/16-18X1.375-IN)4
5S000314 NUT (5/16-18-THD)4
149418215 MOTOR GP-BARRING1
1C056916 BOLT (5/16-18X0.5-IN)5
3V330817 WASHER-HARD (10.2X20.5X2.5-MM THK)2
090129618 U-BOLT2
1K697919 SETSCREW-HEX SOCKET (1/4-20-THD)2
7M324820 BUTTON-PLUG1
2B794721 KEY (SQUARE)1
5M289423 WASHER-HARD (10.2X18.5X2.5-MM THK)4
9S875224 NUT-FULL (3/8-16-THD)4
5P568425 SEAL1
9X540726 SWITCH AS-BALL1
7N7779SOCKET-CONNECTOR (14-GA TO 18-GA)2
7N7780PIN-CONNECTOR (14-GA TO 18-GA)2
7N8205HOUSING-PLUG1
3J190727 SEAL-O-RING1
