System And Components
7E-2495 BARRING & MOUNTING GP (CHG -00 THRU -03, -03D1, -03D2, -04)
Group No: 7E-2495
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P3109 | 1 BRACKET AS | 1 | |
| 6V3538 | DOWEL | 2 | |
| 7W0193 | 2 SPACER (26.65X44X10-MM THK) | 1 | |
| 7W0194 | 3 GUIDE | 1 | |
| 4T4027 | 4 SPRING | 1 | |
| 7C5885 | 5 WASHER (24.5X41X3-MM THK) | 1 | |
| 6H6109 | 6 RING-SNAP | 1 | |
| 4P3111 | 7 SHAFT-PINION | 1 | |
| 7W0196 | 8 GUIDE | 1 | |
| 9S8748 | 9 NUT-FULL (1/4-28-THD) | 1 | |
| 5H9573 | 10 KNOB-CHOKE | 1 | |
| 7W0195 | 11 STEM | 1 | |
| 5L1091 | 12 SPRING | 1 | |
| 3B8489 | 13 FITTING-GREASE | 1 | |
| 9S4191 | 14 PLUG (9/16-18-THD) | 1 | |
| 3J1907 | 15 SEAL-O-RING | 2 | |
| 9X5407 | 16 SWITCH AS-BALL (NEUTRAL START) | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 2 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 2 | |
| 7N8205 | HOUSING-PLUG | 1 | |
| 0S1585 | 17 BOLT (1/2-13X1.5-IN) | 4 | |
| 9S4182 | 18 PLUG (7/16-20-THD) | 2 | |
| 3J7354 | 19 SEAL-O-RING | 2 | |
| 8T6764 | 20 PLUG-PIPE (1/8-27-THD) | 1 | |
| 5P3456 | 21 SEAL-O-RING | 2 |
