System And Components
152-2109 LINES GP-AIR (CHG -00 THRU -02)
Group No: 152-2109
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W4766 | 1 GASKET | 1 | |
| 2147568 | 2 SEAL-O-RING | 2 | |
| 2274056 | 3 GASKET | 2 | |
| 1532391 | 4 ADAPTER | 1 | |
| 7W7629 | 5 HOUSING | 1 | |
| 9S4191 | 6 PLUG (9/16-18-THD) | 2 | |
| 1477645 | 7 ELBOW | 1 | |
| 1477702 | 8 HOUSING | 1 | |
| 1477703 | 9 ELBOW | 1 | |
| 2224710 | 10 BELLOWS AS | 2 | |
| 0S1587 | 11 BOLT (1/2-13X1.75-IN) | 2 | |
| 0S1588 | 12 BOLT (3/8-16X1.25-IN) | 2 | |
| 0S1591 | 13 BOLT (3/8-16X1.5-IN) | 40 | |
| 0S1571 | 14 BOLT (3/8-16X1.75-IN) | 8 | |
| 1A1460 | 15 BOLT (1/2-13X2-IN) | 10 | |
| 1F7958 | 16 NUT-FULL (1/2-13-THD) | 10 | |
| 3V3308 | 17 WASHER-HARD (10.2X20.5X2.5-MM THK) | 58 | |
| 5P1076 | 18 WASHER-HARD (13.5X30X4-MM THK) | 22 | |
| 6V5102 | 19 SEAL-O-RING | 6 | |
| 2A4639 | 20 BOLT (3/8-16X1.625-IN) | 8 |
