System And Components
4P-8034 BARRING & MOUNTING GP (CHG -00-00D1 THRU -02, -02D1, -02D2, -02D3, -02D4, -02D5, -02D6)
Group No: 4P-8034
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P8035 | 1 BRACKET AS | 1 | |
| 6V3538 | DOWEL | 4 | |
| 0S1585 | 2 BOLT (1/2-13X1.5-IN) | 6 | |
| 4P8036 | 3 REDUCER GP-SPEED | 1 | |
| 4K5175 | 4 BOLT-12 POINT HEAD (1/2-13X1.5-IN) | 4 | |
| 5P8245 | 5 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 1806982 | 6 SHAFT-PINION | 1 | |
| 3B8489 | 7 FITTING-GREASE (1/8-27 PTF) | 1 | |
| 9S1302 | 8 WASHER (27X44.45X2.5-MM THK) | 3 | |
| 9Y4709 | 9 SPRING (HIGH IDLE) | 1 | |
| 4P8038 | 10 COLLAR | 1 | |
| 5P8215 | 11 SEAL-O-RING | 2 | |
| 1806981 | 12 RETAINER | 1 | |
| 4P8040 | 13 HOUSING | 1 | |
| 4B3388 | 14 BOLT (5/16-18X1.125-IN) | 4 | |
| 9M1974 | 15 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9S4191 | 16 PLUG (9/16-18-THD) | 1 | |
| 3J1907 | 17 SEAL-O-RING | 1 | |
| 7C7807 | 18 ADAPTER | 1 | |
| 2B7947 | 19 KEY (SQUARE) | 1 | |
| 4B9808 | 20 SETSCREW (1/4-20X0.5-IN) | 2 | |
| 7W0196 | 21 GUIDE | 1 | |
| 9S8748 | 22 NUT-FULL (1/4-28-THD) | 1 | |
| 5H9573 | 23 KNOB-CHOKE | 1 | |
| 7W0195 | 24 STEM | 1 | |
| 5L1091 | 25 SPRING | 1 | |
| 5S2586 | 26 BOLT (3/8-16X1.75-IN) | 1 |
