System And Components
144-9549 BARRING & MOUNTING GP (CHG -00 THRU -03)50:1
Group No: 144-9549
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1449551 | 1 BRACKET AS | 1 | |
| 6V3538 | DOWEL | 4 | |
| 0S1587 | 2 BOLT (1/2-13X1.75-IN) | 6 | |
| 4P8036 | 3 REDUCER GP-SPEED | 1 | |
| 1806982 | 4 SHAFT-PINION | 1 | |
| 4P8038 | 5 COLLAR | 1 | |
| 5P8215 | 6 SEAL-O-RING | 2 | |
| 7W0196 | 7 GUIDE | 1 | |
| 7W0195 | 8 STEM | 1 | |
| 5H9573 | 9 KNOB-CHOKE | 1 | |
| 9S8748 | 10 NUT-FULL (1/4-28-THD) | 1 | |
| 5L1091 | 11 SPRING | 1 | |
| 3B8489 | 12 FITTING-GREASE (1/8-27 PTF) | 1 | |
| 4K5175 | 13 BOLT-12 POINT HEAD (1/2-13X1.5-IN) | 4 | |
| 5P8245 | 14 WASHER-HARD (13.5X25.5X3-MM THK) | 10 | |
| 4B3388 | 15 BOLT (5/16-18X1.125-IN) | 4 | |
| 9M1974 | 16 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 4P8040 | 17 HOUSING | 1 | |
| 1806981 | 18 RETAINER | 1 | |
| 9S1302 | 19 WASHER (27X44.45X2.5-MM THK) | 3 | |
| 9Y4709 | 20 SPRING | 1 | |
| 9X5407 | 21 SWITCH AS-BALL | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 2 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 2 | |
| 7N8205 | HOUSING-PLUG | 1 | |
| 3J1907 | 22 SEAL-O-RING | 1 | |
| 7C7807 | 23 ADAPTER | 1 | |
| 4B9808 | 24 SETSCREW (1/4-20X0.5-IN) | 2 | |
| 2B7947 | 25 KEY (SQUARE) | 1 | |
| 5S2586 | 26 BOLT (3/8-16X1.75-IN) | 1 |
