System And Components
7Y-8016 LINES GP-STICKS/N 8WJ1-UP; 1JM1-UP
Group No: 7Y-8016
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I7884 | 1 TUBE AS | 1 | |
| 1560722 | 2 HOSE AS | 2 | |
| 4I7885 | 3 TUBE AS | 1 | |
| 7X2556 | 4 BOLT (M16X2X100-MM) | 8 | |
| 1P3706 | 5 SEAL-RECTANGULAR | 2 | |
| 1031311 | 6 SUPPORT AS | 2 | |
| 8T4132 | NUT (M16X2-THD) | 2 | |
| 8T4193 | 7 BOLT (M16X2X50-MM) | 8 | |
| 9X8257 | 8 WASHER (17.5X30X3.5-MM THK) | 28 | |
| 6W3731 | 9 SPACER (19.07X26.99X14-MM THK) | 8 | |
| 1031303 | 10 CLAMP-HALF | 4 | |
| 7X2553 | 11 BOLT (M16X2X40-MM) | 4 | |
| 1P3705 | 12 SEAL-RECTANGULAR | 4 | |
| 1031310 | 13 SUPPORT AS | 2 | |
| 1031311 | SUPPORT AS | 1 | |
| 8T4132 | NUT (M16X2-THD) | 2 | |
| 5P8077 | 14 FLANGE-HALF | 8 | |
| 8T4140 | 15 BOLT (M16X2X60-MM) | 16 |
