System And Components
6E-0019 CYLINDER GP-STICKS/N 6NK1-UP; 9WL1-UP
Group No: 6E-0019
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6E0488 | 1 CYLINDER AS | 1 | |
| 6E0781 | BUSHING | 1 | |
| 4I6329 | 2 NUT | 1 | |
| 7I8122 | 3 STOP | 1 | |
| 1163516 | 4 NUT-SELF LOCKING (M120X2-THD) | 1 | |
| 6E0496 | 5 RING-WEAR | 1 | |
| 8C9182 | 6 SEAL AS | 1 | |
| 1163517 | 7 PISTON | 1 | |
| 1163518 | 8 STOP | 1 | |
| 0951733 | 9 SEAL-O-RING | 1 | |
| 4I6442 | 10 RING-BACKUP | 1 | |
| 1289262 | 11 BUSHING | 1 | |
| 1038361 | 12 HEAD | 1 | |
| 8T4167 | 13 WASHER-HARD (26X44X4-MM THK) | 12 | |
| 7X2454 | 14 BOLT (M24X3X110-MM) | 12 | |
| 1425151 | 15 ROD AS | 1 | |
| 6E0781 | BUSHING | 1 | |
| 1659296 | 16 SEAL-LIP TYPE | 1 | |
| 8C9191 | 17 SEAL-U-CUP | 1 | |
| 8C9193 | 18 SEAL-BUFFER | 1 | |
| 8C9192 | 19 RING-BACKUP | 1 | |
| 4I6443 | 20 RING | 1 | |
| 1163519 | 21 RING-SEAL | 1 | |
| 0951274 | 22 SETSCREW-SOCKET (M6X1X16-MM) | 1 | |
| 1038364 | 23 RING-RETAINING | 1 | |
| 1560627 | KIT-SEAL | 1 |
