System And Components
234-5723 LINES GP-BOOM CYLINDER -BOOM LOWERING CONTROLS/N FDL1-UP
Group No: 234-5723
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1031311 | 1 SUPPORT AS | 6 | |
| 1734793 | 2 BLOCK | 2 | |
| 1764722 | 3 BLOCK | 2 | |
| 2356641 | 4 SUPPORT AS | 4 | |
| 2356642 | 5 SUPPORT AS | 2 | |
| 2992132 | 6 BRACKET | 1 | |
| 3267825 | 7 TUBE AS | 1 | |
| 3267826 | 8 TUBE AS | 1 | |
| 3278812 | 9 TUBE AS | 1 | |
| 3278813 | 10 TUBE AS | 1 | |
| 3282520 | 11 BRACKET | 1 | |
| 1P3704 | 12 SEAL-RECTANGULAR | 2 | |
| 1P3705 | 13 SEAL-RECTANGULAR | 4 | |
| 1P3706 | 14 SEAL-RECTANGULAR | 2 | |
| 7X2554 | 16 BOLT (M16X2X70-MM) | 8 | |
| 8T4139 | 17 BOLT (M12X1.75X30-MM) | 12 | |
| 8T4140 | 18 BOLT (M16X2X60-MM) | 8 | |
| 8T4183 | 19 BOLT (M12X1.75X40-MM) | 8 | |
| 8T4223 | 20 WASHER-HARD (13.5X25.5X3-MM THK) | 14 | |
| 8T4648 | 21 BOLT (M12X1.75X70-MM) | 16 | |
| 9X8257 | 22 WASHER (17.5X30X3.5-MM THK) | 8 |
