System And Components
174-1854 VALVE GP-CONTROL -RIGHT HANDS/N ANS1-UP
Group No: 174-1854
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3J7694 | 1 SPRING | 1 | |
| 4J9780 | 2 PLUG-ORIFICE | 1 | |
| 6E3993 | 3 PLUG AS | 6 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 1480767 | RING-SPLIT | 1 | |
| 1006211 | 5 PISTON | 3 | |
| 1459529 | 8 COVER | 1 | |
| 1460182 | 9 BLOCK-MANIFOLD | 1 | |
| 1543294 | 10 MANIFOLD & VALVE GP (PILOT) | 1 | |
| 1543295 | 11 MANIFOLD & VALVE GP (PILOT) | 1 | |
| 1639401 | 12 COVER | 1 | |
| 1693640 | 13 BODY-VALVE | 1 | |
| 1999707 | 14 COVER | 1 | |
| 2224737 | 15 PLUG AS | 7 | |
| 4J7533 | SEAL-O-RING | 1 | |
| 9S4180 | PLUG | 1 | |
| 0058164 | 17 PLUG | 1 | |
| 1098040 | 18 PLUG-ORIFICE | 2 | |
| 1110336 | 19 VALVE GP-SHUTTLE | 1 | |
| 1447113 | 20 VALVE GP-RELIEF (LOAD SENSING DIFF PRESSURE) | 1 | |
| 1488405 | 21 PLUG AS | 3 | |
| 1J9671 | SEAL-O-RING | 1 | |
| 3K8460 | PLUG (1/2-20-THD) | 1 | |
| 1488407 | 22 PLUG AS | 7 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 1488408 | 23 PLUG AS | 3 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 9S4183 | PLUG (1-1/16-12-THD) | 1 | |
| 1488410 | 24 PLUG AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 9S4190 | PLUG-O-RING (7/8-14-THD) | 1 | |
| 1608734 | 25 VALVE GP-RELIEF (LINE) | 1 | |
| 1733993 | 26 PLUG AS | 2 | |
| 4J7533 | SEAL-O-RING | 1 | |
| 9S8001 | PLUG (5/16-24-THD) | 1 | |
| 1837262 | 28 PLUG AS | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 9S8010 | PLUG | 1 | |
| 1837263 | 29 PLUG AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 1H5728 | 30 SEAL-O-RING | 3 | |
| 1P3705 | 31 SEAL-RECTANGULAR | 1 | |
| 1P3706 | 32 SEAL-RECTANGULAR | 3 | |
| 1W6523 | 33 PLUG | 4 | |
| 2D6392 | 34 SEAL-O-RING | 3 | |
| 3D2824 | 35 SEAL-O-RING | 1 | |
| 3F8845 | 36 SPRING | 1 | |
| 3J7354 | 37 SEAL-O-RING | 4 | |
| 4J5309 | 38 SEAL-O-RING | 2 | |
| 4J5573 | 39 SEAL-O-RING | 1 | |
| 4J9535 | 40 SEAL-O-RING | 2 | |
| 4T1860 | 41 VALVE GP-SHUTTLE (BALL RESOLVER) | 1 | |
| 4T5076 | 42 RING-BACKUP | 1 | |
| 5G6401 | 43 BOSS | 2 | |
| 5J5004 | 44 PLUG-ORIFICE | 3 | |
| 6J7240 | 45 SPRING | 2 | |
| 6V0357 | 46 SEAL-O-RING | 1 | |
| 6V5555 | 47 SEAL-O-RING | 2 | |
| 7X2546 | 48 BOLT (M10X1.5X180-MM) | 8 | |
| 7X2553 | 49 BOLT (M16X2X40-MM) | 4 | |
| 7X2555 | 50 BOLT (M16X2X80-MM) | 8 | |
| 7X2557 | 51 BOLT (M16X2X140-MM) | 6 | |
| 8T4197 | 52 BOLT (M8X1.25X40-MM) | 4 | |
| 8T5436 | 53 BOLT (M10X1.5X130-MM) | 8 |
