System And Components
217-3492 VALVE GP-MAIN CONTROLS/N SDL1-UP
Group No: 217-3492
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3J3679 | 1 PLUG AS | 1 | |
| 1J9671 | SEAL-O-RING | 1 | |
| 9S8003 | PLUG (1/2-20-THD) | 1 | |
| 8T4223 | 2 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 4J9780 | 3 PLUG-ORIFICE | 1 | |
| 1639401 | 4 COVER | 2 | |
| 1655623 | 5 MANIFOLD-INLET | 1 | |
| 1931665 | 6 VALVE GP-PRESSURE REDUCING | 1 | |
| 2173490 | 7 VALVE GP-CONTROL (LH) | 1 | |
| 2224737 | 8 PLUG AS | 16 | |
| 4J7533 | SEAL-O-RING | 1 | |
| 9S4180 | PLUG | 1 | |
| 2237748 | 9 VALVE GP-CONTROL (RH) | 1 | |
| 9X8257 | 10 WASHER (17.5X30X3.5-MM THK) | 10 | |
| 1175269 | 11 VALVE GP-RELIEF (LOW SIGNAL PRESSURE) | 1 | |
| 1175270 | 12 VALVE GP-RELIEF (HIGH SIGNAL PRESSURE) | 1 | |
| 1192265 | 13 FILTER (EDGE) | 1 | |
| 1488407 | 14 PLUG AS | 5 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 1488411 | 15 PLUG AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 1553624 | 16 PLUG AS | 4 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 9S4182 | PLUG (7/16-20-THD) | 1 | |
| 1713685 | 17 VALVE GP-SOLENOID (24-VOLT)(HIGH/LOW RELIEF) | 1 | |
| 1P3704 | 18 SEAL-RECTANGULAR | 1 | |
| 1P3707 | 19 SEAL-RECTANGULAR | 4 | |
| 1P5767 | 20 FLANGE-HALF | 2 | |
| 3J1907 | 21 SEAL-O-RING | 1 | |
| 4J0522 | 22 SEAL-O-RING | 4 | |
| 4J5309 | 23 SEAL-O-RING | 4 | |
| 4T1860 | 24 VALVE GP-SHUTTLE (BALL RESOLVER) | 1 | |
| 5P0048 | 25 COVER | 1 | |
| 6V5555 | 26 SEAL-O-RING | 5 | |
| 8T0348 | 27 BOLT-SOCKET HEAD (M16X2X50-MM) | 8 | |
| 8T4193 | 28 BOLT (M16X2X50-MM) | 2 | |
| 8T4194 | 29 BOLT (M12X1.75X50-MM) | 4 | |
| 8T4197 | 30 BOLT (M8X1.25X40-MM) | 8 |
