System And Components
223-7757 VALVE GP-MAIN CONTROLS/N SDL1-UP
Group No: 223-7757
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2237747 | 1 VALVE GP-CONTROL (RH) | 1 | |
| 9X8257 | 2 WASHER (17.5X30X3.5-MM THK) | 10 | |
| 4J9780 | 3 PLUG-ORIFICE | 1 | |
| 1639401 | 4 COVER | 2 | |
| 1655623 | 5 MANIFOLD-INLET | 1 | |
| 1931665 | 6 VALVE GP-PRESSURE REDUCING (SIGNAL DUPLICATION) | 1 | |
| 9S8003 | 7 PLUG (1/2-20-THD) | 1 | |
| 2237742 | 8 VALVE GP-CONTROL (RH) | 1 | |
| 1175269 | 9 VALVE GP-RELIEF (LOW SIGNAL PRESSURE) | 1 | |
| 1175270 | 10 VALVE GP-RELIEF (HIGH SIGNAL PRESSURE) | 1 | |
| 1192265 | 11 FILTER (EDGE) | 1 | |
| 1713685 | 12 VALVE GP-SOLENOID (24-VOLT)(NEUTRAL BYPASS) | 1 | |
| 1J9671 | 13 SEAL-O-RING | 1 | |
| 1P3704 | 14 SEAL-RECTANGULAR | 1 | |
| 1P3707 | 15 SEAL-RECTANGULAR | 4 | |
| 1P5767 | 16 FLANGE-HALF | 2 | |
| 3J1907 | 17 SEAL-O-RING | 6 | |
| 3J7354 | 18 SEAL-O-RING | 4 | |
| 3K0360 | 19 SEAL-O-RING | 1 | |
| 4J0522 | 20 SEAL-O-RING | 4 | |
| 4J5309 | 21 SEAL-O-RING | 4 | |
| 4J7533 | 22 SEAL-O-RING | 16 | |
| 4T1860 | 23 VALVE GP-SHUTTLE (BALL RESOLVER)(LOAD SIGNAL) | 1 | |
| 5P0048 | 24 COVER | 1 | |
| 6V5555 | 25 SEAL-O-RING | 5 | |
| 8T0348 | 26 BOLT-SOCKET HEAD (M16X2X50-MM) | 8 | |
| 8T4193 | 27 BOLT (M16X2X50-MM) | 2 | |
| 8T4194 | 28 BOLT (M12X1.75X50-MM) | 4 | |
| 8T4197 | 29 BOLT (M8X1.25X40-MM) | 8 | |
| 8T4223 | 30 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 9S4180 | 31 PLUG | 16 | |
| 9S4182 | 32 PLUG (7/16-20-THD) | 4 | |
| 9S4185 | 33 PLUG (3/4-16-THD) | 1 | |
| 9S4191 | 34 PLUG (9/16-18-THD) | 5 |
