System And Components
Assembly
100%

128-1064 FRAME GP-UPPERS/N 6XK147-160

Group No: 128-1064
Part NumberPart NameQty
13750301 FRAME AS-UPPER1
1195486PLATE-SKIRT (1750-MM)(SKIRT REPAIR)1
1195487PLATE-SKIRT (1545-MM)(SKIRT REPAIR)1
7I03192 PIN AS2
4I69623 PIN AS2
7X25734 BOLT (M24X3X40-MM)4
8T41675 WASHER-HARD (26X44X4-MM THK)4
09303776 SPACER (143X210X14-MM THK)2
09300777 SHIM (1-MM THK)4
7Y92758 SHIM (1.5-MM THK)2
09301099 SHIM (2-MM THK)2
093007610 SHIM (1-MM THK)4
099746811 SHIM (1.5-MM THK)2
093010812 SHIM (2-MM THK)2
7Y926713 SPACER (133X190X14-MM THK)2
4I318314 WASHER (26X70X8-MM THK)4
4E872615 PIN1
4E873016 PLATE2
8T418317 BOLT (M12X1.75X40-MM)6
8T422318 WASHER-HARD (13.5X25.5X3-MM THK)6
