System And Components
420-1753 PUMP GP-PISTON -STEERINGS/N H9K353-UP
Group No: 420-1753
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1709900 | 1 PIN | 2 | |
| 4237938 | 2 ROTATING GP-PUMP (STEERING) | 1 | |
| 3J1907 | 3 SEAL-O-RING | 3 | |
| 1709907 | 4 PLUG | 2 | |
| 1453171 | 5 LOCKNUT-SEAL | 2 | |
| 1453169 | 6 PIN-THREADED | 2 | |
| 5H4909 | 7 SEAL-O-RING | 1 | |
| 6E1024 | 8 VALVE GP-PUMP CONTROL (PRESSURE, FLOW COMPENSATOR)(STEERING) | 1 | |
| 1175716 | 9 PIN | 4 | |
| 9T3928 | 10 PLUG AS | 4 | |
| 1878001 | SEAL | 1 | |
| 4237939 | 11 HEAD GP-PUMP (STEERING) | 1 | |
| 1833241 | 12 FLANGE | 1 | |
| 0968058 | 13 RING-RETAINING | 2 | |
| 3K0715 | 14 SEAL-O-RING | 1 | |
| 9S9334 | 15 PLUG (1-5/16-12-THD) | 2 | |
| 7M8485 | 16 SEAL-O-RING | 2 | |
| 1770359 | 17 BOLT-SOCKET HEAD (M22X2.5X90-MM) | 4 | |
| 2H3935 | 18 SEAL-O-RING | 1 | |
| 1646944 | 19 IMPELLER | 1 | |
| 1359991 | 20 COUPLING | 1 | |
| 8T4944 | 21 BOLT-SOCKET HEAD (M16X2X40-MM) | 4 | |
| 9S8004 | 22 PLUG (9/16-18-THD) | 3 | |
| 2494488 | 23 ACTUATOR GP-PUMP (MINIMUM ANGLE) | 1 | |
| 2242561 | 24 ACTUATOR GP-PUMP (MAXIMUM ANGLE) | 1 |
