System And Components
508-6443 LINES GP-WATER -NRS COOLERS/N BDN1-4154
Group No: 508-6443
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T9588 | 1 SEAL-O-RING | 1 | |
| 3048008 | 2 PLUG AS | 1 | |
| 6V9027 | SEAL-O-RING | 1 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 3381556 | 3 RETAINER | 2 | |
| 3441816 | 4 ELBOW | 1 | |
| 3498402 | 5 TUBE (INTEGRAL SEAL) | 1 | |
| 3559558 | 6 ELBOW | 1 | |
| 3888922 | 7 ELBOW | 1 | |
| 4456881 | 8 HOSE | 1 | |
| 5234273 | 9 CLAMP-BAND | 2 | |
| 4808231 | 10 TUBE AS-WATER | 1 | |
| 4808232 | 11 TUBE AS-WATER | 1 | |
| 0S0509 | 12 BOLT (3/8-16X0.75-IN) | 2 | |
| 4950924 | 13 BRACKET AS | 1 | |
| 1187214 | 14 SEAL-O-RING | 2 | |
| 0L1351 | 15 BOLT (3/8-16X0.875-IN) | 1 | |
| 1B9575 | 16 BOLT (5/16-18X1.56-IN) | 2 | |
| 1H5514 | 17 BOLT (5/16-18X1.625-IN) | 2 | |
| 3E4352 | 18 WASHER-HARD (8.8X20.5X2.5-MM THK) | 1 | |
| 4F7957 | 19 BOLT (1/4-20X0.875-IN) | 2 | |
| 5M2894 | 20 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 5P0537 | 21 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 7L6580 | 22 SEAL-O-RING | 2 | |
| 8S0023 | 23 CLIP (SLOT) | 2 | |
| 8S0024 | 24 CLIP (TAB) | 2 | |
| 9M1974 | 25 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9X6458 | 26 WASHER-HARD (10.2X22.5X3-MM THK) | 1 | |
| 0S1618 | 27 BOLT (5/16-18X1-IN) | 1 |
