System And Components
110-2576 LINES GP-BRAKE -REARS/N 3BJ200-UP
Group No: 110-2576
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6P4603 | 1 FILTER GP-OIL (WITH HOUSING) | 1 | |
| 4L6454 | 2 BOLT (3/8-16X1-IN) | 6 | |
| 8T4896 | 3 WASHER-HARD (10.2X18.5X2.5-MM THK) | 9 | |
| 5P7462 | 4 CLIP (SLOT) | 2 | |
| 5P7463 | CLIP (TAB) | 2 | |
| 9T4769 | 5 VALVE GP-BRAKE (PARKING & SECONDARY) | 1 | |
| 3K0360 | 6 SEAL-O-RING | 5 | |
| 6V8632 | 7 CONNECTOR | 4 | |
| 7J9108 | 8 SEAL-O-RING | 6 | |
| 2M9780 | 9 SEAL-O-RING | 3 | |
| 6V8626 | 10 ELBOW | 2 | |
| 9M8406 | 11 CLIP (LOOP) | 4 | |
| 5S7379 | 12 BOLT (3/8-16X0.875-IN) | 2 | |
| 8W9919 | 13 TUBE AS | 1 | |
| 8W9917 | 14 TUBE AS | 1 | |
| 8W9916 | 15 TUBE AS | 1 | |
| 8W9918 | 16 TUBE AS | 1 | |
| 2G5536 | 17 BLOCK AS | 1 | |
| 2G5538 | PLATE | 1 | |
| 8X5564 | 18 HOSE AS | 1 | |
| 3J1907 | 19 SEAL-O-RING | 1 | |
| 6V8723 | 20 ELBOW | 1 | |
| 6V8397 | 21 SEAL-O-RING | 1 | |
| 6V8398 | 22 SEAL-O-RING | 2 | |
| 6V8721 | 23 ELBOW | 1 | |
| 1S0994 | 24 CLIP (LOOP) | 4 | |
| 5S7382 | 25 BOLT (3/8-16X1.375-IN) | 2 | |
| 6V8801 | 26 NUT (3/8-16-THD) | 1 | |
| 8X5563 | 27 HOSE AS | 1 | |
| 8W3406 | 28 CYLINDER GP-AIR/HYDRAULIC (REAR)(BRAKE OIL) | 1 | |
| 5T5973 | 29 PLATE | 1 | |
| 8T4122 | 30 WASHER-HARD (17X32X3.5-MM THK) | 5 | |
| 7X3192 | 31 BOLT (5/8-18X2-IN) | 3 | |
| 7X0345 | 32 BOLT (5/8-11X1.75-IN) | 2 | |
| 7X0448 | 33 NUT (5/8-11-THD) | 2 | |
| 8W9915 | 34 PLATE | 1 | |
| 8T4223 | 35 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 5P1075 | 36 WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 1102225 | 37 TANK GP-AIR (MAKEUP) | 1 | |
| 8W5173 | 38 HOSE AS | 1 | |
| 8T7521 | 39 ELBOW | 1 | |
| 1031741 | 40 HOSE AS | 1 | |
| 8J8197 | 41 CLIP | 1 | |
| 5C6565 | 42 BOLT (1/2-13X1.125-IN) | 4 | |
| 5T6974 | 43 HOSE AS | 1 | |
| 4S4455 | 44 CLIP | 2 | |
| 8W9813 | 45 HOSE AS | 1 | |
| 6D4636 | 46 CLIP (LOOP) | 1 | |
| 1P4578 | 47 FLANGE-HALF | 6 | |
| 4J0522 | SEAL-O-RING | 3 | |
| 8T8916 | 48 BOLT (7/16-14X1.5-IN) | 12 | |
| 8T5360 | WASHER (12X22.5X2.5-MM THK) | 12 | |
| 5M3062 | 49 BOLT (3/8-16X0.75-IN) | 1 | |
| 6D7573 | 50 CLIP | 1 | |
| 6V8723 | 51 ELBOW | 1 | |
| 6V8397 | 52 SEAL-O-RING | 4 | |
| 5P7462 | 53 CLIP (SLOT) | 1 | |
| 5P7463 | CLIP (TAB) | 1 | |
| 5S7382 | 54 BOLT (3/8-16X1.375-IN) | 1 | |
| 3J7354 | 55 SEAL-O-RING | 1 | |
| 6V9872 | 56 CONNECTOR | 1 | |
| 3D2824 | 57 SEAL-O-RING | 5 | |
| 6V9007 | 58 ELBOW | 3 | |
| 6V9746 | 59 SEAL-O-RING | 7 | |
| 8T9391 | 60 BOLT (1/2-13X3.75-IN) | 4 | |
| 8T4223 | 61 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 6V9846 | 62 TEE | 1 | |
| 8R8228 | 63 HOSE AS | 1 | |
| 6Y9908 | 64 HOSE AS | 1 | |
| 9S4185 | 65 PLUG (3/4-16-THD) | 1 | |
| 3K0360 | 66 SEAL-O-RING | 2 | |
| 8W9814 | 67 HOSE AS | 1 | |
| 9T3752 | 68 VALVE-CHECK | 1 | |
| 6V8941 | 69 REDUCER | 1 | |
| 6V9850 | 70 ELBOW | 1 | |
| 8W9816 | 71 HOSE AS | 1 | |
| 8W9815 | 72 HOSE AS | 1 | |
| 8W9817 | 73 HOSE AS | 1 | |
| 4S4455 | 74 CLIP | 2 | |
| 6V8556 | 75 NUT (1-3/16-12-THD) | 1 | |
| 8T8900 | 76 TEE-O-RING PORT | 1 | |
| 6V9853 | 77 ELBOW | 1 | |
| 6D4636 | 78 CLIP (LOOP) | 1 | |
| 4L6459 | 79 BOLT (3/8-16X2.5-IN) | 1 | |
| 5P1075 | 80 WASHER-HARD (10.2X22.5X3-MM THK) | 3 | |
| 3H4656 | 81 SPACER (1.5-IN THK) | 1 | |
| 1K4649 | 82 SPACER (0.516X1X1-IN THK) | 1 | |
| 7X0326 | 83 BOLT (1/2-13X3-IN) | 1 | |
| 5P7466 | 84 CLIP (SLOT) | 1 | |
| 5P7467 | CLIP (TAB) | 1 | |
| 5P8112 | 85 GROMMET | 1 | |
| 9B7237 | 86 BOLT (3/8-16X1.25-IN) | 1 | |
| 5P1075 | 87 WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 5P7464 | 88 CLIP (SLOT) | 1 | |
| 5P7465 | CLIP (TAB) | 1 | |
| 6V1249 | 89 GROMMET (22-MM ID) | 1 | |
| 8T2502 | 90 BOLT (3/8-16X1.125-IN) | 1 | |
| 6V8398 | 91 SEAL-O-RING | 7 | |
| 6V8633 | 92 CONNECTOR | 1 | |
| 3D2824 | 93 SEAL-O-RING | 5 | |
| 6V3965 | 94 FITTING (QUICK DISCONNECT) | 2 | |
| 3J1907 | 95 SEAL-O-RING | 6 | |
| 6V0852 | 96 CAP-DUST | 2 | |
| 2G6535 | 97 SLACK ADJUSTER GP | 1 | |
| 8C4436 | 98 BOLT (1/2-13X1.375-IN) | 2 | |
| 8T4223 | 99 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 7J9108 | 100 SEAL-O-RING | 2 | |
| 6V8632 | 101 CONNECTOR | 2 | |
| 3K0360 | 102 SEAL-O-RING | 7 | |
| 6V9746 | 103 SEAL-O-RING | 3 | |
| 6V9004 | 104 ELBOW | 3 | |
| 6V8625 | 105 ELBOW | 1 | |
| 8X6603 | 106 HOSE AS | 1 | |
| 6V8774 | 107 TEE | 1 | |
| 6V8397 | 108 SEAL-O-RING | 6 | |
| 3G2887 | 109 VALVE GP-DIVERTER (BRAKE OIL) | 1 | |
| 6V8775 | 110 TEE-FACE SEAL | 1 | |
| 6V8723 | 111 ELBOW | 2 | |
| 8T6876 | 112 ELBOW | 1 | |
| 8J5604 | 113 BREATHER AS (REAR BRAKE MASTER CYLINDER) | 1 | |
| 6V9876 | 114 ELBOW | 1 | |
| 2M9780 | 115 SEAL-O-RING | 1 | |
| 6V8638 | 116 CONNECTOR | 1 | |
| 6V9851 | 117 ELBOW | 1 | |
| 1125738 | 118 HOSE AS | 1 | |
| 8T5429 | 119 ELBOW | 1 | |
| 6V8724 | 120 ELBOW | 1 | |
| 8T4896 | 121 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 5S7383 | BOLT (3/8-16X1.75-IN) | 2 | |
| 9D6937 | 122 BRACKET | 1 | |
| 9S4191 | 123 PLUG (9/16-18-THD) | 3 |
