Assembly
100%

229-5779 AXLE GPS/N DAR1-UP; EAS1-UP

Group No: 229-5779
Part NumberPart NameQty
31203301 WHEEL & FINAL DRIVE GP2
20879092 SHAFT2
8T41993 BOLT (M8X1.25X12-MM)9
6V83364 BOLT (M12X1.75X70-MM)10
03046056 SEAL-O-RING1
21121877 PLUG3
20879119 WASHER-THRUST4
208790310 COVER1
311253711 HOUSING AS (DIFFERENTIAL)1
311253612 HOUSING AS (DIFFERENTIAL)1
211271413 BOLT (M12X1.25X30-MM)12
208790814 GASKET1
208790715 PLATE10
208790516 PLATE-END2
208790617 PLATE8
7T934419 CONE-BEARING1
7T934520 CUP-BEARING1
211439921 BEARING AS1
192468622 SEAL-LIP TYPE1
4F902923 SEAL1
311237824 RING-RETAINING1
312034025 FLANGE-MOTOR1
208791426 NUT-RING (M20X1.5-THD)1
208791527 COUPLING1
211268928 WASHER1
208791629 SLEEVE1
101740430 BOLT-SOCKET HEAD (M10X1.5X30-MM)8
9R700331 BEARING-TAPERED ROLLER2
233273432 PIN-SPRING3
208790134 BLOCK1
311253836 HOUSING-AXLE1
152614537 PLUG-MAGNETIC (AXLE)2
7X479938 SEAL-O-RING2
055199039 VENT1
6V584440 BOLT (M16X2X35-MM)32
208785041 KIT-SHIM2
211159442 KIT-SHIM1
211159543 KIT-SPACER1
208779744 KIT-SHIM1
2113642KIT-DIFFERENTIAL4
2113641KIT-GEAR1
