System And Components
500-3100 DOOR GP-CAB -LHS/N EJ41-UP
Group No: 500-3100
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2521864 | 1 LATCH AS (LH) | 1 | |
| 2531817 | 2 SPACER (6.5X14.5X12-MM THK) | 1 | |
| 2541126 | 3 PLATE | 1 | |
| 2583697 | 4 WASHER-NYLON (7X20X2-MM THK) | 1 | |
| 3822255 | 5 SPACER (12X20X50-MM THK) | 2 | |
| 3822262 | 6 SEAL | 1 | |
| 3822263 | 7 GLASS | 1 | |
| 3822275 | 8 HINGE | 2 | |
| 3822374 | 9 HANDLE AS | 1 | |
| 3822375 | 10 GASKET | 1 | |
| 4247515 | 11 KEEPER | 1 | |
| 4435722 | 12 SEAL | 1 | |
| 4811860 | 13 WINDOW GP-DOOR (FRONT) | 1 | |
| 4811864 | 14 WINDOW GP-DOOR (REAR) | 1 | |
| 4990734 | 15 SPRING GP-GAS (CAB DOOR) | 1 | |
| 5003099 | 16 DOOR AS-CAB | 1 | |
| 1293180 | 17 LOCKNUT (M12X1.75-THD) | 2 | |
| 1748131 | 18 SCREW-TRUSS HEAD (M4X0.7X12-MM) | 2 | |
| 1783336 | 19 NUT-HEX FLANGE (M8X1.25-THD) | 2 | |
| 4B4863 | 20 WASHER (4.7X11X1.2-MM THK) | 2 | |
| 5C8312 | 21 NUT (M4X0.7-THD) | 2 | |
| 5C9553 | 22 BOLT (M6X1X16-MM) | 3 | |
| 5P4116 | 23 WASHER-HARD (8.8X20.5X2-MM THK) | 4 | |
| 6V5217 | 24 BOLT (M8X1.25X20-MM) | 4 | |
| 8T5412 | 25 BOLT (M12X1.75X140-MM) | 2 | |
| 8U5746 | 26 BOLT (M6X1X75-MM) | 1 | |
| 9X2045 | 27 SCREW-TRUSS HEAD (M6X1X20-MM) | 4 | |
| 9X8256 | 28 WASHER (6.6X12X2-MM THK) | 2 |
