System And Components
382-2243 DOOR GP-CAB -LHS/N DYN1-UP
Group No: 382-2243
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3822208 | 1 WINDOW GP-DOOR (REAR, LH) | 1 | |
| 3822255 | 2 SPACER (12X20X50-MM THK) | 2 | |
| 4990759 | 3 DOOR AS | 1 | |
| 3822260 | 4 WINDOW GP-DOOR (LH) | 1 | |
| 3822374 | 5 HANDLE AS | 1 | |
| 3822375 | 6 GASKET | 1 | |
| 4435722 | 7 SEAL | 1 | |
| 1293180 | 8 LOCKNUT (M12X1.75-THD) | 2 | |
| 1748131 | 9 SCREW-TRUSS HEAD (M4X0.7X12-MM) | 2 | |
| 1783336 | 10 NUT-HEX FLANGE (M8X1.25-THD) | 2 | |
| 2521864 | 11 LATCH AS (LH) | 1 | |
| 2531817 | 12 SPACER (6.5X14.5X12-MM THK) | 1 | |
| 2541126 | 13 PLATE | 1 | |
| 2583697 | 14 WASHER-NYLON (7X20X2-MM THK) | 1 | |
| 3822262 | 15 SEAL | 2 | |
| 3822263 | 16 GLASS | 1 | |
| 3822275 | 17 HINGE | 2 | |
| 4247515 | 18 KEEPER | 1 | |
| 4990734 | 19 SPRING GP-GAS | 1 | |
| 4B4863 | 20 WASHER (4.7X11X1.2-MM THK) | 2 | |
| 5C8312 | 21 NUT (M4X0.7-THD) | 2 | |
| 5C9553 | 22 BOLT (M6X1X16-MM) | 3 | |
| 5P4116 | 23 WASHER-HARD (8.8X20.5X2-MM THK) | 4 | |
| 8T4189 | 24 BOLT (M8X1.25X20-MM) | 4 | |
| 8T5412 | 25 BOLT (M12X1.75X140-MM) | 2 | |
| 8U5746 | 26 BOLT (M6X1X75-MM) | 1 | |
| 9X2045 | 27 SCREW-TRUSS HEAD (M6X1X20-MM) | 4 | |
| 9X8256 | 28 WASHER (6.6X12X2-MM THK) | 2 | |
| 5610725 | 29 SPACER | 4 |
