System And Components
273-6036 SEAT GP -CLOTHS/N BLD1-1594
Group No: 273-6036
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1053481 | 1 BOLT-SOCKET HEAD (M8X1.25X20-MM) | 2 | |
| 1619283 | 2 WASHER (19.8X31.8X1.6-MM THK) | 3 | |
| 1641244 | 3 CUSHION AS-BACK | 1 | |
| 1641249 | 4 LEVER AS (RECLINER CONTROL) | 1 | |
| 1641250 | 5 HANDLE | 1 | |
| 1641251 | 6 SPRING | 1 | |
| 1641252 | 7 SPRING | 1 | |
| 1641253 | 8 PLATE | 1 | |
| 1641254 | 9 SECTOR | 1 | |
| 1641255 | 10 SECTOR | 1 | |
| 1641258 | 11 BRACKET AS (RH) | 1 | |
| 1641259 | 12 BRACKET AS (LH) | 1 | |
| 1805789 | 13 NUT | 1 | |
| 1805796 | 14 CUSHION AS-SEAT | 1 | |
| 1805797 | 15 PAN AS | 1 | |
| 1959223 | 16 SCREW-PAN HEAD (10-14X0.63-IN) | 2 | |
| 2600029 | 17 PAN | 1 | |
| 2600045 | 18 BOLT-SPECIAL | 1 | |
| 3T0852 | 19 LOCKNUT (M8X1.25-THD) | 8 | |
| 1293180 | 20 LOCKNUT (M12X1.75-THD) | 2 | |
| 5P8245 | 21 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4189 | 22 BOLT (M8X1.25X20-MM) | 2 | |
| 8T9501 | 23 SCREW (10-16X0.75-IN) | 2 | |
| 9X6620 | 24 LOCKNUT (M10X1.5-THD) | 1 |
