331-1410 AXLE & TRANSMISSION AR -REARS/N W8R1-5079

Group No: 331-1410
Part NumberPart NameQty
23745461 TRANSMISSION GP (DIRECT DRIVE)1
33380312 HOUSING-AXLE2
33380443 SHAFT-AXLE2
33380344 HOUSING1
11001815 RING (2-MM THK)2
1100182RING (1.95-MM THK)2
1100183RING (1.9-MM THK)2
1100184RING (1.85-MM THK)2
0982962SHIM (1.8-MM THK)2
0982960SHIM (1.6-MM THK)2
0982959SHIM (1.5-MM THK)2
0982958SHIM (1.4-MM THK)2
0982957SHIM (1.3-MM THK)2
1100191RING (1.25-MM THK)2
6T8668SHIM (1.2-MM THK)2
1100192RING (1.15-MM THK)2
6T8669SHIM (1.1-MM THK)2
1100193RING (1.05-MM THK)2
6T8670SHIM (1-MM THK)2
1100194RING (0.95-MM THK)2
1100195RING (0.9-MM THK)2
1100167WASHER (90X99.8X0.85-MM THK)2
6T8671SHIM (0.8-MM THK)2
1100168WASHER (90X99.8X0.75-MM THK)2
6T8672SHIM (0.7-MM THK)2
1100169WASHER (90X99.8X0.65-MM THK)2
6T8673SHIM (0.6-MM THK)2
6T8674SHIM (0.5-MM THK)2
1100177WASHER (90X99.8X0.45-MM THK)2
6T8675SHIM (0.4-MM THK)2
1100178WASHER (90X99.8X0.35-MM THK)2
1100180WASHER (90X99.8X0.3-MM THK)2
1931125SHIM (0.1-MM THK)2
1931127SHIM (0.15-MM THK)2
8U230635 BEARING1
110246336 BEARING-ROLLER1
270496937 SEAL-O-RING2
336738038 BOLT (M18X2.5X65-MM)36
263362940 PLUG AS3
2030215SEAL-O-RING1
203021541 SEAL-O-RING1
263363042 PLUG AS-MAGNET (AXLE)1
8T418343 BOLT (M12X1.75X40-MM)4
6V814944 NUT (M12X1.75-THD)10
331137445 GEAR-CROWN1
331140146 WASHER-THRUST2
366049247 GEAR-DIFFERENTIAL2
366049348 GEAR-DIFFERENTIAL4
331140449 WASHER-THRUST4
333801350 CASE-DIFFERENTIAL1
331140751 SPIDER1
7X243652 BOLT (M12X1.75X100-MM)16
6V820053 BOLT-SOCKET HEAD (M12X1.75X35-MM)4
270384954 HUB GP-WHEEL2
2430378NUT1
5W568255 VALVE AS-PURGE (AXLE)2
8T414056 BOLT (M16X2X60-MM)28
8U607957 SEAL-O-RING2
233874258 GEAR-SUN2
269243059 RING2
121816760 BEARING-ROLLER2
269243161 BEARING-ROLLER2
333803062 HUB-FLANGE2
7X576263 SEAL-O-RING2
263370164 GEAR-CARRIER2
320972865 SEAL-O-RING4
320973166 SEAL-O-RING2
298231467 GEAR-INTERNAL2
328880468 PISTON2
263405769 DOWEL8
355231970 SEAL2
238330371 RING (2-MM THK)2
8U075472 SEAL2
238330473 RING (2-MM THK)2
8U359274 SPRING16
238330575 SPRING16
298231576 BOLT-SPECIAL16
8U359177 SPACER (6.5X15X7-MM THK)16
263370478 DISC-CLUTCH (4.5-MM THK)14
2383309DISC-CLUTCH (2.5-MM THK)14
2383307DISC-CLUTCH (2-MM THK)2
2383308DISC-CLUTCH (3-MM THK)2
110016182 WASHER-THRUST (2.5-MM THK)2
333803583 CAGE-PINION2
333803684 GEAR-PLANETARY6
333805085 BEARING-ROLLER6
110473786 RING-RETAINING6
6V366887 BOLT (M12X1.75X30-MM)4
243533688 BOLT (M10X1.5X20-MM)2
333803789 STUD-WHEEL20
366049490 RING2
