System And Components
348-3684 PAN GP-SEAT -DELUXES/N T4P1-UP
Group No: 348-3684 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4B4278 | 1 WASHER (10.2X20.5X1.6-MM THK) | 4 | |
| 1053481 | 2 BOLT-SOCKET HEAD (M8X1.25X20-MM) | 2 | |
| 1641249 | 3 LEVER AS (RECLINER CONTROL) | 1 | |
| 1641251 | 4 SPRING | 1 | |
| 1641252 | 5 SPRING | 1 | |
| 1641253 | 6 PLATE | 1 | |
| 1641254 | 7 SECTOR | 1 | |
| 1641255 | 8 SECTOR | 1 | |
| 1641256 | 9 SPACER (19X25.4X12.5-MM THK) | 2 | |
| 1641257 | 10 SPACER (19.4X25.4X15.9-MM THK) | 1 | |
| 1641274 | 11 BLOCK | 1 | |
| 1805785 | 12 SPRING | 1 | |
| 1805786 | 13 PUCK | 4 | |
| 1805789 | 14 NUT | 1 | |
| 3249976 | 15 LATCH | 1 | |
| 3249977 | 16 LINK | 1 | |
| 3483685 | 17 PAN AS | 1 | |
| 3483686 | 18 BRACKET AS (LH) | 1 | |
| 3483687 | 19 BRACKET AS (RH) | 1 | |
| 3483697 | 20 PAN AS | 1 | |
| 3484094 | 21 PAN | 1 | |
| 3507591 | 22 BRACKET | 1 | |
| 3T0852 | 23 LOCKNUT (M8X1.25-THD) | 12 | |
| 1293180 | 24 LOCKNUT (M12X1.75-THD) | 2 | |
| 2P7864 | 25 SCREW-TAPPING (1/4-14-THD) | 1 | |
| 4H1641 | 26 PIN-SPRING | 1 | |
| 5P8245 | 27 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6C3678 | 28 RIVET | 4 | |
| 8T4189 | 29 BOLT (M8X1.25X20-MM) | 2 |
