System And Components
352-1449 AIR CLEANER GPS/N LJJ1-UP
Group No: 352-1449
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2764836 | 1 SWITCH-PRESSURE (24-VOLT)(AIR CLEANER) | 1 | |
| 3233309 | 2 CAP | 1 | |
| 3236645 | 3 CAP | 1 | |
| 3393043 | 4 DUCT-AIR | 1 | |
| 3418901 | 5 SUPPORT AS | 1 | |
| 1599540 | NUT-WELD (M8X1.25-THD) | 6 | |
| 3435643 | 6 AIR CLEANER GP | 1 | |
| 4152896 | 7 HOSE | 1 | |
| 3678073 | 8 SEAL | 1 | |
| 4639225 | 9 PLATE-INSTRUCTION (LUBRICATION POINTS) | 1 | |
| 2428009 | 10 SCREW-PAN HEAD (6-19X0.5-IN) | 2 | |
| 2955550 | 11 CLAMP-BAND (CONSTANT TENSION) | 1 | |
| 4H3001 | 12 PLUG-BUTTON | 1 | |
| 5C9553 | 13 BOLT (M6X1X16-MM) | 4 | |
| 5P1717 | 14 CLAMP-HOSE | 1 | |
| 5P4116 | 15 WASHER-HARD (8.8X20.5X2-MM THK) | 4 | |
| 7X7729 | 16 WASHER (11X25X3-MM THK) | 2 | |
| 8T4133 | 17 NUT (M10X1.5-THD) | 2 | |
| 8T4908 | 18 BOLT (M8X1.25X25-MM) | 4 | |
| 9X6165 | 19 WASHER (6.5X22X2.5-MM THK) | 4 |
