System And Components
369-1461 LINES GP-COUPLER -PARALLEL LIFTS/N JXR1-UP
Group No: 369-1461
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3597228 | 1 VALVE GP-CONTROL (REMOTE CONTROL) | 1 | |
| 4490451 | 2 PIN | 2 | |
| 1525717 | 3 CAP-DUST | 1 | |
| 1525718 | 4 CAP-DUST | 1 | |
| 1783713 | 5 CYLINDER GP-COUPLER | 1 | |
| 1956525 | 6 FITTING AS (QUICK DISCONNECT, FEMALE) | 1 | |
| 1956526 | 7 FITTING AS (QUICK DISCONNECT, MALE) | 1 | |
| 2085149 | 8 ELBOW AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 2085148 | ELBOW | 1 | |
| 3621606 | 9 HOSE AS | 1 | |
| 3621607 | 10 HOSE AS | 2 | |
| 3621610 | 11 TUBE AS | 1 | |
| 1488315 | 12 CONNECTOR AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8642 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488336 | 13 CONNECTOR AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488345 | 14 CONNECTOR AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8638 | CONNECTOR | 1 | |
| 1488378 | 15 ELBOW AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1488439 | 16 TEE AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8774 | TEE | 1 | |
| 2119032 | 17 WASHER-HARD (8.8X13X2-MM THK) | 2 | |
| 5P7465 | 18 CLIP (TAB) | 2 | |
| 6V7359 | 19 GROMMET (25-MM ID, 37-MM OD) | 2 | |
| 6V8213 | 20 BOLT-SOCKET HEAD (M8X1.25X70-MM) | 2 | |
| 6W5760 | 21 DOWEL | 2 | |
| 8T4121 | 22 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4133 | 23 NUT (M10X1.5-THD) | 2 | |
| 8T4186 | 24 BOLT (M10X1.5X40-MM) | 2 | |
| 8T4646 | 25 CLIP (SLOT) | 2 | |
| 3922926 | 26 HOSE AS | 1 |
