System And Components
353-1388 CONTROL GP-HYDRAULIC PEDAL -AUXILIARY, EXTENDABLE STICKS/N RAK1-UP
Group No: 353-1388
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4773 | 1 BALL JOINT | 2 | |
| 8T6431 | 2 ROD END | 2 | |
| 1338916 | 3 FILM-INSTRUCTION (EXTENDABLE STICK) | 1 | |
| 1980098 | 4 FILM-INSTRUCTION (AUXILIARY) | 1 | |
| 3988245 | 5 PIN | 1 | |
| 2312875 | 6 SUPPORT AS (RH) | 1 | |
| 2312876 | 7 PEDAL AS (RH) | 1 | |
| 2321540 | 8 SEAL | 1 | |
| 3533433 | 9 SHAFT AS | 1 | |
| 3665457 | 10 PLATE AS | 1 | |
| 3665460 | 11 ROD | 1 | |
| 3665461 | 12 ROD | 1 | |
| 3892016 | 13 PLATE AS | 1 | |
| 0364453 | 14 RING-RETAINING | 2 | |
| 6V7744 | 15 LOCKNUT (M10X1.5-THD) | 3 | |
| 1617632 | 16 BOLT-SELF-LOCKING (M10X1.5X40-MM) | 1 | |
| 8M3175 | 17 WASHER-HARD (10.2X16X3-MM THK) | 1 | |
| 8T4121 | 18 WASHER-HARD (11X21X2.5-MM THK) | 10 | |
| 8T4133 | 19 NUT (M10X1.5-THD) | 6 | |
| 8T4186 | 20 BOLT (M10X1.5X40-MM) | 1 | |
| 8T4195 | 21 BOLT (M10X1.5X30-MM) | 4 | |
| 3992810 | 22 CLIP | 1 |
