System And Components
309-1324 LINES GP-HYDRAULIC FANS/N T5A116-UP
Group No: 309-1324
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P9299 | 1 CLIP (LOOP) | 1 | |
| 2501424 | 2 ELBOW AS | 2 | |
| 6V8724 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 8M2773 | 3 CLIP (LOOP) | 1 | |
| 3095137 | 4 CONNECTOR AS | 1 | |
| 6V8635 | CONNECTOR | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3400852 | 5 MANIFOLD GP-CONTROL (HYDRAULIC FAN, STEERING) | 1 | |
| 3579557 | 6 HOSE AS | 1 | |
| 3727570 | 7 HOSE AS | 1 | |
| 3774706 | 8 HOSE AS | 1 | |
| 3789447 | 9 HOSE AS | 1 | |
| 3789448 | 10 HOSE AS | 1 | |
| 1195916 | 11 CLIP | 1 | |
| 1790469 | 12 SPACER (11X20X40-MM THK) | 4 | |
| 1488368 | 13 ELBOW AS | 1 | |
| 6V8627 | ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 1488369 | 14 ELBOW AS | 1 | |
| 6V8628 | ELBOW | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 1697394 | 15 CONNECTOR AS | 1 | |
| 8C3370 | CONNECTOR | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 1771061 | 16 ELBOW AS | 1 | |
| 1420038 | ELBOW | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 1S0994 | 17 CLIP (LOOP) | 6 | |
| 1S1015 | 18 CLIP (LOOP) | 2 | |
| 2065017 | 19 SPACER (11X20X5-MM THK) | 1 | |
| 2287093 | 20 SEAL-O-RING | 2 | |
| 2815936 | 21 ELBOW AS | 1 | |
| 8C8762 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 8T4136 | 22 BOLT (M10X1.5X25-MM) | 1 | |
| 3196240 | 23 CONNECTOR AS | 2 | |
| 6V9873 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2901993 | 24 STRAP-CABLE | 2 | |
| 3E7407 | 26 TEE-SWIVEL-ORFS | 1 | |
| 4D7388 | 27 CLIP | 3 | |
| 5L7674 | 30 SPACER (12.5X17.1X69.85-MM THK) | 1 | |
| 5P7468 | 31 CLIP (SLOT) | 1 | |
| 5P7469 | 32 CLIP (TAB) | 1 | |
| 5P8444 | 33 GROMMET (37-MM ID) | 1 | |
| 6D1641 | 34 CLIP (LOOP) | 1 | |
| 8T4121 | 35 WASHER-HARD (11X21X2.5-MM THK) | 12 | |
| 8T4133 | 36 NUT (M10X1.5-THD) | 2 | |
| 8T4137 | 37 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4195 | 38 BOLT (M10X1.5X30-MM) | 3 | |
| 8T4198 | 39 BOLT (M10X1.5X100-MM) | 3 | |
| 8T5005 | 40 BOLT (M10X1.5X70-MM) | 3 | |
| 8T6466 | 41 BOLT (M10X1.5X60-MM) | 1 | |
| 8T7934 | 42 WASHER-HARD (11X21X5-MM THK) | 2 | |
| 9X2503 | 43 CLIP | 1 | |
| 3158639 | 44 SLEEVE (83-CM) |
