System And Components
387-6615 WIRING GP-REAR -SIDESHIFTS/N LYG1-UP
Group No: 387-6615
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1545428 | 1 ALARM AS | 1 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 1649425 | 2 HORN AS (12-VOLT, LOW TONE) | 1 | |
| 2059920 | 3 STRAP-CABLE | 9 | |
| 3876547 | 4 SWITCH AS-ROCKER (SIDESHIFT, LOCK-UNLOCK) | 1 | |
| 3876549 | 5 SWITCH AS-ROCKER (HORN) | 1 | |
| 1117899 | GASKET | 1 | |
| 3876616 | 6 HARNESS AS-REAR | 1 | |
| 3926850 | 7 BRACKET AS | 1 | |
| 1599539 | NUT-WELD (M6X1-THD) | 2 | |
| 2812901 | 8 SCREW-BUTTON HEAD (M10X1.5X40-MM) | 1 | |
| 3S2093 | 9 STRAP-CABLE | 11 | |
| 4P7428 | 10 CLIP (LADDER) | 2 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4133 | 12 NUT (M10X1.5-THD) | 3 | |
| 8T4196 | 13 BOLT (M10X1.5X35-MM) | 2 | |
| 9X2042 | 14 SCREW-TRUSS HEAD (M6X1X12-MM) | 2 | |
| 9X6165 | 15 WASHER (6.5X22X2.5-MM THK) | 2 | |
| 1650312 | 16 WIRE AS (18-GA) | 1 | |
| 1409378 | 17 RELAY AS (12-VOLT) | 1 | |
| 7K1181 | 18 STRAP-CABLE | 1 |
