System And Components
393-2033 LINES GP-STEERING -ALL WHEEL DRIVE, ALL WHEEL STEER, STD SHIFTS/N LYL1-UP
Group No: 393-2033
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4264133 | 1 ELBOW AS | 1 | |
| 6V5325 | SEAL-O-RING | 1 | |
| 6V5330 | RING-RETAINING | 1 | |
| 4264132 | ADAPTER-ELBOW | 1 | |
| 4540097 | 2 CLIP | 3 | |
| 2062423 | 3 SADDLE-MOUNTING | 2 | |
| 2681559 | 4 ADAPTER AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 2090939 | ADAPTER | 1 | |
| 3622820 | 5 CAP | 2 | |
| 3736998 | 6 VALVE GP-STEERING (ALL WHEEL STEER) | 1 | |
| 3861602 | 7 HOSE AS | 1 | |
| 3861604 | 8 HOSE AS | 2 | |
| 3882495 | 9 BRACKET AS | 1 | |
| 3934154 | 10 HOSE AS | 1 | |
| 3934155 | 11 HOSE AS | 1 | |
| 3981506 | 12 HOSE AS | 1 | |
| 3981508 | 13 HOSE AS | 1 | |
| 4152269 | 14 SEAL | 1 | |
| 4242971 | 15 VALVE-CHECK | 1 | |
| 1004336 | 17 CLIP (LOOP) | 3 | |
| 1488318 | 18 CONNECTOR AS | 4 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8634 | CONNECTOR | 1 | |
| 1488369 | 19 ELBOW AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8628 | ELBOW | 1 | |
| 1488374 | 20 ELBOW AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8723 | ELBOW | 1 | |
| 1488383 | 21 ELBOW AS | 3 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T1683 | ELBOW | 1 | |
| 1645605 | 22 CONNECTOR AS | 4 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T0076 | CONNECTOR | 1 | |
| 2349525 | 23 STUD (M10X1.5-THD) | 1 | |
| 2372228 | 24 BOLT (M10X1.5X70-MM) | 1 | |
| 2395030 | 25 ADAPTER AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9X2493 | ADAPTER | 1 | |
| 2B0941 | 26 SPACER (10.5X19X19-MM THK) | 2 | |
| 3597325 | 27 CLAMP-HOSE | 2 | |
| 4264131 | 28 ADAPTER AS | 1 | |
| 1559644 | SEAL | 1 | |
| 4264129 | ADAPTER | 1 | |
| 4P7429 | 29 CLIP (LADDER) | 1 | |
| 7X7729 | 30 WASHER (11X25X3-MM THK) | 3 | |
| 8T4121 | 31 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4137 | 32 BOLT (M10X1.5X20-MM) | 3 | |
| 8T4172 | 33 BOLT (M10X1.5X80-MM) | 1 | |
| 8T4182 | 34 BOLT (M10X1.5X45-MM) | 1 | |
| 8T4200 | 35 BOLT (M8X1.25X16-MM) | 2 | |
| 8T4224 | 36 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9R3884 | 37 SPACER (13X20X45-MM THK) | 1 | |
| 9X6772 | 38 STRAP-CABLE | 11 | |
| 1952037 | 39 FITTING AS | 1 | |
| 0343679 | ADAPTER | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 4861876 | 40 HOSE | 1 |
