468-7975 KIT-CONTROL VALVE -EXCAVATORS/N HWA1-UP

Group No: 468-7975

Part Number	Part Name	Qty
8T5381	1 PIN AS-SPRING	2
1641399	2 KNOB	2
1641435	3 PLATE	2
1706312	4 BEARING	4
3907515	5 TOWER AS	1
1599541	NUT-WELD (M10X1.5-THD)	2
3911293	6 SHAFT	1
3915422	7 LEVER AS (LH)(LH)	1
1641436	7A BEARING	1
3915423	8 LEVER AS (RH)(RH)	1
1641436	8A BEARING	1
3988074	9 ROD AS	1
4188515	10 ROD AS	1
4357651	BALL JOINT	1
4468059	ROD	1
8T4133	NUT (M10X1.5-THD)	2
8T5063	ROD END	1
4188517	11 ROD AS	2
3912709	ROD AS	1
4357651	BALL JOINT	1
8T4133	NUT (M10X1.5-THD)	1
4260313	12 SEAL	1
4309927	13 FILM-IDENTIFICATION (EXCAVATOR CONTROL)	1
4373580	14 MOUNT	4
4393492	15 ROD AS	1
8T4133	NUT (M10X1.5-THD)	2
8T5063	ROD END	1
4357651	BALL JOINT	1
4393493	ROD	1
4393495	16 PIN	4
4393496	17 BRACKET AS	2
3856511	17A BUSHING	2
4394932	18 ROD AS	1
4403614	19 BOSS	1
4540097	20 CLIP	2
1641402	21 SLEEVE	2
1641404	22 SPACER (10.67X16.95X23-MM THK)	2
1895358	23 BOLT (M10X1.5X60-MM)	4
5C2890	24 NUT (M6X1-THD)	6
6V3964	25 WASHER-HARD (8.8X25.5X5-MM THK)	1
6V9824	26 RING-RETAINING	3
7X2537	27 BOLT (M8X1.25X35-MM)	1
7X7729	28 WASHER (11X25X3-MM THK)	10
8T0389	29 LOCKNUT (M10X1.5-THD)	10
8T4121	30 WASHER-HARD (11X21X2.5-MM THK)	10
8T4133	31 NUT (M10X1.5-THD)	4
8T4138	32 BOLT (M6X1X20-MM)	6
8T4172	33 BOLT (M10X1.5X80-MM)	2
8T4205	34 WASHER-HARD (7.2X14.5X2-MM THK)	6
8T4222	35 WASHER-PLATED (11X32X2.5-MM THK)	4
8T4224	36 WASHER-HARD (8.8X16X2-MM THK)	1
8T4908	37 BOLT (M8X1.25X25-MM)	1
8T6466	38 BOLT (M10X1.5X60-MM)	2
9R2807	39 CLIP (RETAINER)	4
