System And Components
444-1425 SHAFT GP-DRIVE -REVERSES/N HWC1-UP
Group No: 444-1425
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0050469 | 1 CUP-BEARING | 1 | |
| 6V8144 | 2 RING-RETAINING | 1 | |
| 3837974 | 3 GEAR (41-TEETH) | 1 | |
| 9X7684 | 4 SEAL-O-RING | 1 | |
| 0050471 | 5 CONE-BEARING | 1 | |
| 3837984 | 6 SEAL-RING | 2 | |
| 3837989 | 7 WASHER-THRUST | 1 | |
| 3837990 | 8 WASHER-THRUST | 1 | |
| 4259214 | 9 BEARING-NEEDLE | 1 | |
| 4385164 | 10 BEARING-TAPERED ROLLER | 1 | |
| 4429960 | 11 SPRING-RETURN | 1 | |
| 4429962 | 12 SPRING-RETAINER | 1 | |
| 4433302 | 13 PLATE-CLUTCH | 10 | |
| 4673151 | 14 DISC-FRICTION | 10 | |
| 4437550 | 15 GEAR (23-TEETH) | 1 | |
| 4441421 | 16 PISTON | 1 | |
| 4441423 | 17 SHAFT AS-REVERSE | 1 | |
| 3838018 | PLUG | 2 | |
| 4437546 | DRUM AS | 1 | |
| 4441670 | 18 PLATE-END | 1 | |
| 4475547 | 19 SLEEVE | 1 | |
| 1H8128 | 20 SEAL-O-RING | 1 | |
| 2613255 | 21 RING-RETAINING | 1 | |
| 4259210 | 22 BEARING | 1 |
