337-9830 FRAME GP-SWINGS/N HWC1-UP
Group No: 337-9830
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1361122 | 1 SPACER (13.8X25X10-MM THK) | 1 | |
| 2096850 | 2 PIN AS | 1 | |
| 2375330 | 3 PIN | 2 | |
| 2807732 | 4 WASHER (76.5X130X8-MM THK) | 2 | |
| 3410597 | 5 FRAME AS | 1 | |
| 2136702 | 5A BUSHING | 4 | |
| 2370944 | 5B BUSHING | 2 | |
| 2785454 | 5C BUSHING | 2 | |
| 3419483 | 6 PIN | 1 | |
| 3419484 | 7 PIN AS | 1 | |
| 3419488 | 8 PIN | 2 | |
| 3B8489 | 9 FITTING-GREASE (1/8-27 PTF) | 4 | |
| 6V4364 | 10 RING-RETAINING | 4 | |
| 6V7687 | 11 LOCKNUT (M12X1.75-THD) | 3 | |
| 7X0542 | 12 WASHER-HARD (51X74X3-MM THK) | 2 | |
| 8T4139 | 13 BOLT (M12X1.75X30-MM) | 2 | |
| 8T4821 | 14 WASHER (13.5X40X3-MM THK) | 2 | |
| 8T7930 | 15 BOLT (M12X1.75X160-MM) | 3 | |
| 9R7882 | 16 SPACER (14X25X7-MM THK) | 1 | |
| 4653495 | 17 GUARD | 1 |
