Assembly
100%

382-2206 CAB GPS/N HWC1-UP

Group No: 382-2206
Part NumberPart NameQty
12937381 GUARD-STRIKER2
17481312 SCREW-TRUSS HEAD (M4X0.7X12-MM)4
21064753 PLATE2
21903024 FILM-WARNING (NO WELD, NO DRILL, READ OMM)1
32208195 INSERT-THREADED (M10X1.5-THD)1
33833286 BOLT-STRIKER (M12X1.75X57.5-MM)2
38222518 SEAL2
38223109 GLASS (REAR LOWER, LH)1
382231110 GLASS (REAR LOWER, RH)1
382234211 WINDOW-FRONT1
382234312 GLASS (FRONT LOWER, LH)1
382234413 GLASS (FRONT LOWER, RH)1
424751514 KEEPER2
424964415 FILM-INFORMATION (ROPS, FOPS, READ OMM)1
443572316 SEAL2
463613717 INSERT-THREADED (M4X0.7-THD)4
463613818 INSERT-THREADED (M6X1-THD)58
463613919 INSERT-THREADED (M8X1.25-THD)31
4B486320 WASHER (4.7X11X1.2-MM THK)4
561072521 SPACER22
5C831222 NUT (M4X0.7-THD)4
8T482123 WASHER (13.5X40X3-MM THK)2
