System And Components
417-0509 CONTROL GP-HYDRAULIC HAND -HYBRIDS/N HWC1-UP
Group No: 417-0509
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4743 | 1 PIN | 2 | |
| 1641368 | 2 FASTENER (CLIP) | 6 | |
| 2061345 | 3 STRAP-CABLE | 2 | |
| 3876625 | 4 CONTROL GP-HANDLE | 1 | |
| 3887048 | 5 BRACKET AS | 1 | |
| 4492128 | 5A BUSHING | 1 | |
| 3897230 | 6 PIN | 1 | |
| 3897232 | 7 LEVER AS | 1 | |
| 3884733 | 7A BUSHING | 1 | |
| 3897244 | 8 PIN | 1 | |
| 3908024 | 9 PIN AS | 1 | |
| 3908743 | 10 ROD AS | 1 | |
| 8T4133 | NUT (M10X1.5-THD) | 1 | |
| 8T4773 | BALL JOINT | 1 | |
| 9X2065 | NUT (M10X1.5-THD, LH) | 1 | |
| 4542225 | ROD | 1 | |
| 4543053 | BALL JOINT | 1 | |
| 3952917 | 11 PLATE | 1 | |
| 4152274 | 12 SEAL | 1 | |
| 4188609 | 13 ROD AS | 1 | |
| 8T4133 | NUT (M10X1.5-THD) | 2 | |
| 8T4773 | BALL JOINT | 1 | |
| 8T4815 | ROD END | 1 | |
| 3908822 | STUD (M10X1.5-MM) | 1 | |
| 4232610 | 14 ROD GP (LOADER CONTROL) | 1 | |
| 4309943 | 15 FILM-CONTROL (LOADER, JOYSTICK) | 1 | |
| 4540097 | 16 CLIP | 4 | |
| 1382042 | 17 LOCKNUT (M10X1.5-THD) | 2 | |
| 1704735 | 18 RING-RETAINING | 5 | |
| 5H3193 | 19 PIN-SPRING | 1 | |
| 5P4116 | 20 WASHER-HARD (8.8X20.5X2-MM THK) | 2 | |
| 6V7744 | 21 LOCKNUT (M10X1.5-THD) | 4 | |
| 7X0510 | 22 WASHER-HARD (15.5X29X3-MM THK) | 1 | |
| 7X7729 | 23 WASHER (11X25X3-MM THK) | 2 | |
| 8T4121 | 24 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4136 | 25 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4189 | 26 BOLT (M8X1.25X20-MM) | 2 |
