System And Components
438-9128 CONTROL GP-TRANSMISSIONS/N HWC1-UP
Group No: 438-9128
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 2 | |
| 9R1766 | 2 COVER-BOTTOM | 1 | |
| 9R1767 | 3 BOOT | 1 | |
| 1028802 | 4 KIT-RECEPTACLE (2-PIN) | 1 | |
| 1641153 | 5 KNOB (UPPER) | 1 | |
| 1641368 | 6 FASTENER (CLIP) | 4 | |
| 2637261 | 7 SWITCH GP-PUSH BUTTON (NEUTRALIZER) | 1 | |
| 5P5677 | WIRE (18-GA, BLACK) | ||
| 6V2689 | TUBE-HEAT SHRINK (6.35-MM DIA)(1.3-M) | ||
| 9W0625 | SWITCH AS-PUSH BUTTON | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 2 | |
| 4703683 | 8 ROD AS | 1 | |
| 3952912 | 9 BOOT | 1 | |
| 3952914 | 10 PLATE | 1 | |
| 1D5120 | 11 NUT-JAM (3/4-16-THD) | 1 | |
| 8T4223 | 12 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8T4183 | 13 BOLT (M12X1.75X40-MM) | 1 | |
| 8T9501 | 14 SCREW (10-16X0.75-IN) | 2 | |
| 8T4121 | 15 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4133 | 16 NUT (M10X1.5-THD) | 4 | |
| 8T4182 | 17 BOLT (M10X1.5X45-MM) | 4 | |
| 4558433 | 18 MOUNT AS | 4 | |
| 4652558 | 19 BLOCK AS | 1 | |
| 4653313 | 20 PLATE | 1 |
