System And Components
573-9208 SEAT & MOUNTING GP -FABRICS/N HWC1-UP
Group No: 573-9208
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1595 | 1 BOLT (1/2-13X1.25-IN) | 2 | |
| 1959223 | 2 SCREW-PAN HEAD (10-14X0.63-IN) | 4 | |
| 1K6872 | 3 LOCKNUT (1/2-13-THD) | 2 | |
| 1V0358 | 4 WASHER (8.6X33.3X1.2-MM THK) | 4 | |
| 2203790 | 5 ARMREST AS (RH) | 1 | |
| 2203791 | 6 ARMREST AS (LH) | 1 | |
| 6A9083 | SCREW-MACHINE (M6X1X15-MM) | 1 | |
| 3242900 | 7 BRACKET | 1 | |
| 3242901 | 8 BRACKET | 1 | |
| 5664717 | 9 KIT-SEAT FRAME | 1 | |
| 5725842 | 10 CUSHION AS-BACK | 1 | |
| 5739213 | 11 CUSHION AS-SEAT | 1 | |
| 5P8245 | 12 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4908 | 13 BOLT (M8X1.25X25-MM) | 4 | |
| 8T9501 | 14 SCREW (10-16X0.75-IN) | 2 |
