Assembly
100%

382-2260 WINDOW GP-DOOR -LHS/N HWC1-UP

Group No: 382-2260
Part NumberPart NameQty
42486771 PLUG AS2
42486822 WASHER-RUBBER (11.5X34X3-MM THK)2
12532983 BOLT-SOCKET HEAD (M5X0.8X12-MM)2
20982964 BOLT-SOCKET HEAD (M8X1.25X25-MM)2
12985425 RETAINER1
12985456 WASHER (13X40X3-MM THK)2
13641927 BOLT (M6X1X35-MM)1
29969868 LATCH GP-CAB DOOR & WINDOW1
33004279 LATCH GP (LH)1
382226110 GLASS (LH)1
382227011 BUSHING2
382227712 HINGE2
382234713 WASHER-RUBBER (32.5X55X6-MM THK)4
398495014 HANDLE1
