System And Components
331-8526 BRAKE GP-SERVICEPART OF 331-8523 HOUSING GP-AXLE
Group No: 331-8526
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1048081 | 1 PLUG AS | 1 | |
| 1704825 | 2 SEAL-O-RING | 1 | |
| 1990670 | 3 SCREW-PURGE | 1 | |
| 1990672 | 4 SPACER-SPECIAL | 3 | |
| 1990701 | 5 COVER-BRAKE | 3 | |
| 3318503 | 6 BUSHING | 6 | |
| 3318516 | 7 PLATE | 1 | |
| 3318517 | 8 HOUSING-BRAKE | 1 | |
| 3318519 | 9 PISTON-BRAKE | 1 | |
| 1990681 | 10 WASHER (6.2X16.5X2-MM THK) | 3 | |
| 1990702 | 11 SPRING (INNER) | 3 | |
| 1990703 | 12 SPRING (OUTER) | 3 | |
| 1R5396 | 13 BOLT (M6X1X35-MM) | 3 | |
| 2246081 | 14 SEAL-O-RING | 1 | |
| 5P9880 | 15 RIVET-POP | 2 | |
| 6V2315 | 16 BOLT (M6X1X35-MM) | 3 | |
| 8F6230 | 17 SEAL-O-RING | 1 | |
| 2043055 | 19 KIT-BRAKE CYLINDER (SPRING RETENTION) | 1 | |
| 2043102 | 20 KIT-BRAKE CYLINDER (ADJUSTER) | 1 |
