System And Components
573-9210 SEAT & MOUNTING GP -FABRICS/N L7E1-UP
Group No: 573-9210
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1595 | 1 BOLT (1/2-13X1.25-IN) | 2 | |
| 1641276 | 2 TUBE | 2 | |
| 1641277 | 3 CLIP-SPRING | 2 | |
| 1959223 | 4 SCREW-PAN HEAD (10-14X0.63-IN) | 6 | |
| 1K6872 | 5 LOCKNUT (1/2-13-THD) | 2 | |
| 1V0358 | 6 WASHER (8.6X33.3X1.2-MM THK) | 4 | |
| 2203790 | 7 ARMREST AS (RH) | 1 | |
| 2203791 | 8 ARMREST AS (LH) | 1 | |
| 6A9083 | SCREW-MACHINE (M6X1X15-MM) | 1 | |
| 3242900 | 9 BRACKET | 1 | |
| 3242901 | 10 BRACKET | 1 | |
| 5664718 | 11 KIT-SEAT FRAME | 1 | |
| 5664727 | 12 CUSHION AS-BACK | 1 | |
| 5664728 | 13 KIT-BACKREST | 1 | |
| 5739217 | 14 KIT-SEAT CUSHION | 1 | |
| 8T4908 | 15 BOLT (M8X1.25X25-MM) | 4 |
