System And Components
117-6162 CAB GP-ENCLOSED ROPSS/N 7EJ6000-99999
Group No: 117-6162
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9R7777 | 1 CAB AS | 1 | |
| 7T1099 | LINK | 5 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 26 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 2 | |
| 8T4133 | NUT (M10X1.5-THD) | 14 | |
| 8T6462 | BOSS-WELD (M10X1.5X25-MM) | 6 | |
| 9R1754 | HANDLE | 2 | |
| 9R2821 | BOSS (M10X1.5X15-MM) | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 6 | |
| 8T3636 | STUD-WELD (M8X1.25X32-MM) | 1 | |
| 9R9759 | PLATE AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 1 | |
| 8C3390 | 2 SEAL (85CM) | ||
| 9R7287 | 3 PLATE AS | 1 | |
| 5P5637 | SEAL (1.4M) | ||
| 6V9632 | NUT-WELD (M6X1-THD) | 3 | |
| 8T4133 | 4 NUT (M10X1.5-THD) | 15 | |
| 8T4121 | 5 WASHER-HARD (11X21X2.5-MM THK) | 23 | |
| 8T4137 | 6 BOLT (M10X1.5X20-MM) | 8 | |
| 8T4141 | 7 BOLT (M20X2.5X70-MM) | 4 | |
| 8T4123 | 8 WASHER (22X35X3.5-MM THK) | 8 | |
| 8T4131 | 9 NUT (M20X2.5-THD) | 4 | |
| 9R1937 | 10 PLATE AS (RH) | 1 | |
| 5P5637 | SEAL (0.7M) | ||
| 9R1940 | 11 PLATE AS (LH) | 1 | |
| 5P5637 | SEAL (0.7M) | ||
| 9R5650 | 12 DOOR GP-CAB | 1 | |
| 9R5651 | 13 DOOR GP-CAB | 1 | |
| 8T4195 | 14 BOLT (M10X1.5X30-MM) | 11 | |
| 5C7261 | 15 NUT (M8X1.25-THD) | 2 | |
| 8T4222 | 16 WASHER-PLATED (11X32X2.5-MM THK) | 7 | |
| 0910147 | 17 BUMPER | 2 | |
| 6V1790 | 18 PLUG-BUTTON | 3 | |
| 9R8529 | 19 SEAL | 1 | |
| 2V3726 | 20 BUMPER | 4 | |
| 5P5992 | 21 HOSE (3.1 M) | ||
| 8T4191 | 22 BOLT (M10X1.5X16-MM) | 2 | |
| 9R7880 | 23 CHANNEL | 1 | |
| 9R7875 | 24 CHANNEL | 1 | |
| 1030232 | 25 SEAL (1010CM) | ||
| 8T4133 | 26 NUT (M10X1.5-THD) | 5 | |
| 9R2870 | 27 PLATE | 2 | |
| 8T4121 | 28 WASHER-HARD (11X21X2.5-MM THK) | 13 | |
| 8T4137 | 29 BOLT (M10X1.5X20-MM) | 6 | |
| 8T4136 | 30 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4195 | 31 BOLT (M10X1.5X30-MM) | 3 | |
| 1030233 | 32 SEAL (406CM) | ||
| 9R5515 | 33 GLASS-CAB | 1 | |
| 8R3596 | 34 SEAL (138CM) | ||
| 1030234 | 35 STRIP (1416CM) | ||
| 9R1892 | 36 PLATE | 2 | |
| 9R5512 | 37 GLASS-CAB | 2 | |
| 9R6066 | 38 STRIP-EDGE | 2 | |
| 8T4140 | 39 BOLT (M16X2X60-MM) | 4 | |
| 8T4122 | 40 WASHER-HARD (17X32X3.5-MM THK) | 8 | |
| 8T4132 | 41 NUT (M16X2-THD) | 4 | |
| 5P5921 | 42 SEAL (3.1M) | ||
| 9R5513 | 43 GLASS-CAB | 2 | |
| 9R5516 | 44 GLASS-CAB | 2 | |
| 6V7743 | 45 LOCKNUT (M6X1-THD) | 2 | |
| 9R1966 | 46 SHIM (1.5-MM THK) | 8 | |
| 9R8537 | 47 SOCKET-LATCH | 2 | |
| 8T3991 | 48 SCREW-BUTTON HEAD (M6X1X20-MM) | 6 | |
| 8T4205 | 49 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 9R8138 | 50 WINDOW GP-CAB | 1 | |
| 0S1570 | BOLT (1/4-28X0.625-IN) | 6 | |
| 0S1597 | BOLT (1/4-28X1-IN) | 6 | |
| 3F7674 | LOCKNUT (1/4-28-THD) | 12 | |
| 5C7261 | NUT (M8X1.25-THD) | 2 | |
| 6V8816 | SCREW-MACHINE | 4 | |
| 8T4205 | WASHER-HARD (7.2X14.5X2-MM THK) | 6 | |
| 9R4029 | CATCH-RELEASE (LH) | 1 | |
| 9R4030 | CATCH-RELEASE (RH) | 1 | |
| 9R4031 | BOLT-RELEASE | 2 | |
| 9R4032 | SPRING | 2 | |
| 8Y6896 | GLAZING | 1 | |
| 9R8526 | RAIL AS | 1 | |
| 9R8527 | RAIL AS | 1 | |
| 9R8530 | GLASS-FIXED | 1 | |
| 9R8686 | SEAL | 1 | |
| 9R8688 | GLASS-SLIDING | 1 | |
| 9R9742 | HINGE | 2 | |
| 9R9746 | STRUT-LOCKING | 1 | |
| 9R9753 | CATCH AS (RH) | 1 | |
| 9R9754 | CATCH AS (LH) | 1 | |
| 9R9755 | STRUT-NON-LOCKING | 1 | |
| 4B4161 | SCREW-DRIVE (NO 6X3/8-IN) | 2 | |
| 7X2905 | PLATE-WARNING-ROPS/FOPS | 1 |
