System And Components
180-9873 AIR CONDITIONER GPS/N C5R1-UP
Group No: 180-9873
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P5908 | 1 SEAL (0.1-M) | ||
| 1P6522 | 2 GROMMET | 1 | |
| 2H3922 | 3 LOCKWASHER | 1 | |
| 2H3923 | 4 LOCKWASHER | 1 | |
| 2S3745 | 5 SCREW-TAPPING (10-16X0.5-IN) | 6 | |
| 3B4501 | 6 LOCKWASHER | 2 | |
| 3E1841 | 7 LEVER | 1 | |
| 3E5464 | 8 SWITCH AS-THERMOSTAT (HVAC)(REFRIGERANT) | 1 | |
| 3S2093 | 9 STRAP-CABLE | 1 | |
| 5C9553 | 10 BOLT (M6X1X16-MM) | 4 | |
| 6V1668 | 11 WASHER (6.5X29.1X3-MM THK) | 2 | |
| 7F2050 | 12 LOCKNUT (3/4-16-THD) | 1 | |
| 7F2060 | 13 LOCKNUT (7/8-14-THD) | 1 | |
| 8C4586 | 14 CLAMP | 2 | |
| 8C8457 | 15 SCREW-MACHINE (M5X0.8X14-MM) | 1 | |
| 9X2488 | 16 CLAMP-HOSE | 6 | |
| 8T4171 | 17 BOLT (M6X1X12-MM) | 4 | |
| 8T4205 | 18 WASHER-HARD (7.2X14.5X2-MM THK) | 13 | |
| 8T6631 | 19 SCREW-MACHINE (8-32X0.5-IN) | 2 | |
| 8Y5737 | 20 CLAMP | 1 | |
| 9G1950 | 21 RESISTOR | 1 | |
| 9X2044 | 22 SCREW-TRUSS HEAD (M6X1X16-MM) | 1 | |
| 9X2185 | 23 SCREW (8-15X0.44-IN) | 4 | |
| 0374426 | 24 RETAINER | 1 | |
| 1003143 | 25 PLATE-ORIFICE | 2 | |
| 1003426 | 26 WHEEL AS-BLOWER | 2 | |
| 0374838 | CLAMP | 2 | |
| 1020341 | 27 CLIP | 1 | |
| 1143140 | 28 GROMMET | 1 | |
| 1185044 | 29 HARNESS AS-WIRING (CAB HEATER) | 1 | |
| 6T6505 | HOUSING-RECEPTACLE (BLADE, POSITIVE LOCK) | 5 | |
| 9W0852 | PIN-CONNECTOR (14-GA TO 16-GA) | 5 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 8T8737 | PLUG-SEAL | 1 | |
| 1028805 | KIT-RECEPTACLE (6-PIN) | 1 | |
| 9W0844 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 2 | |
| 3S2093 | STRAP-CABLE | 3 | |
| 6T6506 | TERMINAL-BLADE (14-GA TO 18-GA) | 5 | |
| 1193662 | TUBE-HEAT SHRINK (10.85-MM DIA)(13-CM) | ||
| 1185046 | 30 HOUSING AS | 1 | |
| 7T4567 | BRACKET | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 1 | |
| 1238851 | 31 CASE AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 7 | |
| 1248494 | 32 GASKET | 2 | |
| 1248495 | 33 VALVE AS-WATER (AIR CONDITIONER) | 1 | |
| 1293178 | 34 LOCKNUT (M6X1-THD) | 3 | |
| 1419784 | 35 BOLT (M6X1X190-MM) | 1 | |
| 1510894 | 36 COVER AS | 1 | |
| 7X2478 | NUT-WELD (M8X1.25-THD) | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 1741486 | 37 MOTOR AS-BLOWER (24-VOLT, A/C, HEATER) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 9W0852 | PIN-CONNECTOR (14-GA TO 16-GA) | 2 | |
| 1803528 | 38 COIL AS-EVAPORATOR | 1 | |
| 1891707 | ORIFICE AS-AIR CONDITIONER | 1 | |
| 1837528 | 39 COIL AS-HEATER | 1 | |
| 6V7728 | 40 BOLT (M6X1X45-MM) | 1 | |
| 6V1392 | 41 SEAL (0.6-M) | ||
| 6V1392 | 41A SEAL (0.17-M EACH) | ||
| 1361953 | 42 HOSE (18-CM) | ||
| 1361953 | 42A HOSE (15-CM) | ||
| 1361953 | 42B HOSE (23-CM) | ||
| 8T5372 | 43 SEAL (0.2-M EACH) | ||
| 5P7070 | 44 INSULATION-STRIP (0.6-M EACH) | ||
| 5P5643 | 45 SEAL (0.4-M) |
