System And Components
139-9416 CONTROL GP-HYDRAULIC HANDS/N 8TN1-924; 1FR1-1415
Group No: 139-9416
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8F7702 | 1 SEAL-LIP TYPE | 4 | |
| 8T3984 | 2 KNOB | 2 | |
| 8T4121 | 3 WASHER-HARD (11X21X2.5-MM THK) | 15 | |
| 8T4773 | 4 BALL JOINT | 1 | |
| 8T4815 | 5 ROD END | 12 | |
| 8T6431 | 6 ROD END | 1 | |
| 8T6658 | 7 PIN | 1 | |
| 8T9000 | 8 KNOB | 4 | |
| 9R1968 | 9 SPACER (10.6X13.6X7-MM THK) | 2 | |
| 9R2807 | 10 CLIP (RETAINER) | 16 | |
| 9R3135 | 11 PIN | 3 | |
| 9R4764 | 12 ROD | 1 | |
| 9R8825 | 13 PLATE | 4 | |
| 9R9721 | 14 LEVER AS | 2 | |
| 5V4410 | BUSHING | 1 | |
| 9R9722 | 15 ROD | 2 | |
| 9R9901 | 16 FASTENER (CLIP) | 8 | |
| 0068606 | 17 RING-RETAINING | 2 | |
| 1012788 | 18 FILM-INSTRUCTION (EXTENDABLE STICK) | 1 | |
| 1156455 | 19 LEVER AS | 1 | |
| 5V4410 | BUSHING | 2 | |
| 1156456 | 20 LEVER AS | 1 | |
| 5V4410 | BUSHING | 2 | |
| 1156457 | 21 LEVER AS | 1 | |
| 5V4410 | BUSHING | 2 | |
| 1162449 | 22 SHAFT AS | 1 | |
| 1162452 | 23 PLATE | 1 | |
| 1163016 | 24 LEVER AS | 1 | |
| 5V4410 | BUSHING | 1 | |
| 1163018 | 25 ROD | 1 | |
| 1163019 | 26 ROD | 3 | |
| 1164372 | 27 SHAFT AS | 1 | |
| 1164373 | 28 SHAFT AS | 1 | |
| 1164374 | 29 SUPPORT AS | 1 | |
| 5V4410 | BUSHING | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 3 | |
| 1164375 | 30 SUPPORT AS | 1 | |
| 5V4410 | BUSHING | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 3 | |
| 1164381 | 31 SEAL | 2 | |
| 1164478 | 32 BOSS AS | 1 | |
| 5V4410 | BUSHING | 1 | |
| 1175672 | 33 BOOT | 6 | |
| 1232846 | 34 SUPPORT AS | 1 | |
| 1233119 | 35 PLATE | 2 | |
| 1264358 | 36 PLATE | 2 | |
| 1286151 | 37 FILM-INSTRUCTION | 1 | |
| 1303291 | 38 PLATE AS | 1 | |
| 1303292 | 39 PLATE AS | 1 | |
| 1303293 | 40 ROD AS | 1 | |
| 1303294 | 41 ROD AS | 1 | |
| 1303858 | 42 MAT | 2 | |
| 1367439 | 43 SPACER (20X40X3-MM THK) | 10 | |
| 1367440 | 44 SHIM (1-MM THK) | 14 | |
| 6V7743 | 45 LOCKNUT (M6X1-THD) | 2 | |
| 6V7744 | 46 LOCKNUT (M10X1.5-THD) | 1 | |
| 7X2535 | 47 BOLT (M6X1X60-MM) | 2 | |
| 8T4133 | 48 NUT (M10X1.5-THD) | 16 | |
| 8T4186 | 49 BOLT (M10X1.5X40-MM) | 2 | |
| 8T4195 | 50 BOLT (M10X1.5X30-MM) | 12 | |
| 9R2806 | 51 PIN | 12 | |
| 9X8256 | 52 WASHER (6.6X12X2-MM THK) | 4 | |
| 1411762 | 53 SPACER (21.2X25.4X20-MM THK) | 2 |
