System And Components
9R-5788 LINES GP-MULTIPURPOSE BUCKETS/N FDP18400-UP
Group No: 9R-5788
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V1249 | 1 GROMMET (22-MM ID) | 2 | |
| 7I5486 | 2 HOSE AS | 1 | |
| 9R0418 | 3 HOSE AS | 2 | |
| 1007443 | 4 HOSE AS | 1 | |
| 1007444 | 5 HOSE AS | 1 | |
| 1312127 | 6 HOSE AS | 1 | |
| 1488336 | 7 CONNECTOR AS | 4 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1503060 | 8 TEE AS | 2 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8T3444 | TEE-UNION | 1 | |
| 5P7464 | 9 CLIP (SLOT) | 2 | |
| 5P7465 | 10 CLIP (TAB) | 2 | |
| 8T1891 | 11 CLIP (SLOT) | 4 | |
| 8T1892 | 12 CLIP (TAB) | 4 | |
| 8T4121 | 13 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4136 | 14 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4192 | 15 BOLT (M12X1.75X25-MM) | 2 | |
| 8T4223 | 16 WASHER-HARD (13.5X25.5X3-MM THK) | 2 |
