System And Components
120-9582 LINES GP-HYDRAULICS/N 2CR1-16211
Group No: 120-9582
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P3703 | 1 SEAL-RECTANGULAR | 1 | |
| 1P3709 | 2 SEAL-RECTANGULAR | 1 | |
| 3E7419 | 3 CLAMP-HOSE | 1 | |
| 5D1026 | 4 CLAMP-BAND | 2 | |
| 6V0484 | 5 ELBOW | 1 | |
| 6V0852 | 6 CAP-DUST | 2 | |
| 6V3965 | 7 FITTING (QUICK DISCONNECT) | 2 | |
| 6V5653 | 8 ELBOW (7/8-14-THD) | 2 | |
| 5P4868 | 9 CLAMP-HOSE | 2 | |
| 9S4190 | 10 PLUG-O-RING (7/8-14-THD) | 1 | |
| 1011787 | 11 TEE AS | 1 | |
| 1144777 | 12 BRACKET AS | 1 | |
| 1145535 | 13 HOSE | 1 | |
| 1145536 | 14 FLANGE | 1 | |
| 9M8406 | 15 CLIP (LOOP) | 2 | |
| 1173232 | 16 HOSE AS | 1 | |
| 1173235 | 17 HOSE AS | 1 | |
| 1173240 | 18 HOSE AS | 1 | |
| 1173244 | 19 HOSE AS | 1 | |
| 1212903 | 20 FLANGE | 1 | |
| 5P1505 | 21 HOSE (62CM) | ||
| 2M9780 | 22 SEAL-O-RING | 3 | |
| 3D2824 | 23 SEAL-O-RING | 1 | |
| 3J1907 | 24 SEAL-O-RING | 4 | |
| 3J7354 | 25 SEAL-O-RING | 2 | |
| 4J5477 | 26 SEAL-O-RING | 4 | |
| 5K9090 | 27 SEAL-O-RING | 4 | |
| 5P1506 | 28 HOSE (129CM) | ||
| 6V8641 | 29 CONNECTOR | 1 | |
| 6V8647 | 30 CONNECTOR | 1 | |
| 6V8785 | 31 TEE | 1 | |
| 6V9007 | 32 ELBOW | 1 | |
| 6V9746 | 33 SEAL-O-RING | 2 | |
| 6V9849 | 34 ELBOW | 1 | |
| 6V9854 | 35 ELBOW (SWIVEL) | 1 | |
| 7D7233 | 36 CLIP (LOOP) | 5 | |
| 7M8485 | 37 SEAL-O-RING | 2 | |
| 7X2550 | 38 BOLT (M12X1.75X110-MM) | 1 | |
| 4D7388 | 39 CLIP | 1 | |
| 1102445 | 40 CLAMP-HOSE | 3 | |
| 8T4121 | 41 WASHER-HARD (11X21X2.5-MM THK) | 18 | |
| 8T4133 | 42 NUT (M10X1.5-THD) | 1 | |
| 8T4136 | 43 BOLT (M10X1.5X25-MM) | 7 | |
| 8T4137 | 44 BOLT (M10X1.5X20-MM) | 3 | |
| 8T4191 | 45 BOLT (M10X1.5X16-MM) | 1 | |
| 8T4195 | 46 BOLT (M10X1.5X30-MM) | 3 | |
| 8T4198 | 47 BOLT (M10X1.5X100-MM) | 4 | |
| 8T4223 | 48 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 8T4910 | 49 BOLT (M12X1.75X60-MM) | 2 | |
| 8T6356 | 50 TEE-O-RING PORT | 1 | |
| 6V1889 | 51 CLIP (LOOP) | 1 |
