System And Components
196-1140 LINES GP-COUPLERS/N CJZ275-UP
Group No: 196-1140
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 2 | |
| 1125841 | 2 TUBE AS | 1 | |
| 1125842 | 3 TUBE AS | 1 | |
| 1226404 | 4 CYLINDER & MTG GP-COUPLER | 1 | |
| 1227272 | 5 BLOCK | 1 | |
| 1230431 | 6 HOSE AS | 1 | |
| 1381979 | 7 VALVE & MTG GP-SOLENOID | 1 | |
| 1387779 | 8 HOSE AS | 1 | |
| 1403117 | 9 COVER | 1 | |
| 1482302 | 10 HOSE AS | 1 | |
| 1482303 | 11 HOSE AS | 1 | |
| 1482304 | 12 HOSE AS | 1 | |
| 1482305 | 13 BRACKET | 1 | |
| 1482306 | 14 BRACKET | 1 | |
| 1485367 | 15 PLATE AS | 2 | |
| 1487208 | 16 COVER | 1 | |
| 1488197 | 17 HOSE AS | 1 | |
| 1514841 | 18 BLOCK | 2 | |
| 1525717 | 19 CAP-DUST | 1 | |
| 1684510 | 20 BOLT (M10X1.5X70-MM) | 2 | |
| 1724620 | 21 CONNECTOR AS | 2 | |
| 3D2824 | SEAL-O-RING | 2 | |
| 6Y2349 | CONNECTOR | 1 | |
| 1802531 | 22 HOSE AS | 2 | |
| 1956525 | 23 FITTING AS (QUICK DISCONNECT, FEMALE) | 1 | |
| 1956526 | 24 FITTING AS (QUICK DISCONNECT, MALE) | 1 | |
| 1959878 | 25 CAP-DUST | 1 | |
| 2010947 | 26 VALVE GP-DIVERTER (MAN SHUTOFF, COUPLER, AUX HYD) | 1 | |
| 2151383 | 27 TUBE AS | 1 | |
| 2458176 | 28 TUBE AS | 1 | |
| 1488319 | 29 CONNECTOR AS | 3 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8715 | CONNECTOR | 1 | |
| 1488328 | 30 CONNECTOR AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8633 | CONNECTOR | 1 | |
| 1488341 | 31 CONNECTOR AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 6V8713 | CONNECTOR | 1 | |
| 1488367 | 32 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9850 | ELBOW | 1 | |
| 1488368 | 33 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8627 | ELBOW | 1 | |
| 1488378 | 34 ELBOW AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1488382 | 35 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 8T0404 | ELBOW | 1 | |
| 1488439 | 36 TEE AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8774 | TEE | 1 | |
| 3S2093 | 37 STRAP-CABLE | 1 | |
| 5P7465 | 38 CLIP (TAB) | 4 | |
| 6V1249 | 39 GROMMET (22-MM ID) | 4 | |
| 6V8398 | 40 SEAL-O-RING | 6 | |
| 8T4121 | 41 WASHER-HARD (11X21X2.5-MM THK) | 28 | |
| 8T4136 | 42 BOLT (M10X1.5X25-MM) | 11 | |
| 8T4137 | 43 BOLT (M10X1.5X20-MM) | 5 | |
| 8T4195 | 44 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4201 | 45 BOLT-LOCKING (M10X1.5X20-MM) | 4 | |
| 8T4646 | 46 CLIP (SLOT) | 4 | |
| 9R1004 | 47 CLIP (TAB) | 10 | |
| 9R1005 | 48 CLIP (SLOT) | 10 | |
| 9X2125 | 49 BOLT-LOCKING (M10X1.5X25-MM) | 4 | |
| 1280187 | KIT-HANDLE | 1 |
