System And Components
164-1520 CONTROL GP-HYDRAULIC HAND -BACKHOES/N BGJ523-1315
Group No: 164-1520
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4766 | 1 ROD END | 1 | |
| 8T4773 | 2 BALL JOINT | 1 | |
| 8T4815 | 3 ROD END | 6 | |
| 8T6431 | 4 ROD END | 5 | |
| 9R9901 | 5 FASTENER (CLIP) | 6 | |
| 1012788 | 6 FILM-INSTRUCTION (EXTENDABLE STICK) | 1 | |
| 1090533 | 7 SEAL | 2 | |
| 1175672 | 8 BOOT | 4 | |
| 1367439 | 9 SPACER (20X40X3-MM THK) | 4 | |
| 1367440 | 10 SHIM (1-MM THK) | 3 | |
| 1427405 | 11 COLLAR | 1 | |
| 1641372 | 12 PLATE | 1 | |
| 1641397 | 13 KNOB | 4 | |
| 1641406 | 14 ROD | 1 | |
| 1641427 | 15 ROD | 1 | |
| 1641501 | 16 LEVER AS (BUCKET) | 1 | |
| 1641502 | 17 LEVER AS (STICK) | 1 | |
| 1641503 | 18 LEVER AS (BOOM) | 1 | |
| 1861583 | 19 ROD END AS | 1 | |
| 1641511 | 20 LEVER AS (EXTENDABLE STICK) | 1 | |
| 1641514 | 21 ROD | 3 | |
| 1641515 | 22 SUPPORT AS | 2 | |
| 5V4410 | BUSHING | 2 | |
| 1641517 | 23 SHAFT AS-PEDAL | 2 | |
| 1641519 | 24 SHAFT-LEVER | 1 | |
| 1641521 | 25 SHAFT AS | 1 | |
| 1641523 | 26 BEARING | 2 | |
| 1641525 | 27 ROD | 1 | |
| 1641541 | 28 PEDAL AS (RH) | 1 | |
| 1641551 | 29 PEDAL AS (LH) | 1 | |
| 1641570 | 30 TOWER AS | 1 | |
| 1798235 | 31 LOCK PIN | 5 | |
| 1834999 | 32 CONSOLE-REAR | 1 | |
| 1905129 | 33 FILM (BUCKET CONTROL) | 1 | |
| 1420485 | 34 NUT (M10X1.5-THD) | 1 | |
| 6V7744 | 35 LOCKNUT (M10X1.5-THD) | 7 | |
| 6V8335 | 36 BOLT-SELF-LOCKING (M10X1.5X40-MM) | 2 | |
| 6V8932 | 37 SETSCREW-SOCKET (M6X1X10-MM) | 1 | |
| 8C4987 | 38 PIN-CLEVIS | 5 | |
| 8M3175 | 39 WASHER-HARD (10.2X16X3-MM THK) | 5 | |
| 8T4121 | 40 WASHER-HARD (11X21X2.5-MM THK) | 14 | |
| 8T4133 | 41 NUT (M10X1.5-THD) | 12 | |
| 8T4186 | 42 BOLT (M10X1.5X40-MM) | 5 | |
| 8T4195 | 43 BOLT (M10X1.5X30-MM) | 6 | |
| 8T4224 | 44 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 8T4908 | 45 BOLT (M8X1.25X25-MM) | 4 | |
| 8T7547 | 46 BOLT (M8X1.25X30-MM) | 2 | |
| 9R2806 | 47 PIN | 2 | |
| 9R2807 | 48 CLIP (RETAINER) | 2 | |
| 9X2038 | 49 WASHER (7X19X2-MM THK) | 4 | |
| 9X2043 | 50 SCREW-TRUSS HEAD (M6X1X14-MM) | 4 | |
| 8T4138 | 51 BOLT (M6X1X20-MM) | 6 | |
| 5P4115 | 52 WASHER-HARD (7.2X19X2-MM THK) | 6 | |
| 2414954 | 53 GUARD (RH) | 1 | |
| 2414955 | 54 GUARD (LH) | 1 |
