System And Components
228-5730 CONTROL GP-HYDRAULIC HAND -STABILIZERS/N WEP1-UP; TDR1-UP
Group No: 228-5730
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2108914 | 1 PLATE | 1 | |
| 2108917 | 2 LEVER GP-CONTROL VALVE (STABILIZER) | 2 | |
| 8T0328 | WASHER-HARD (5.5X10X1-MM THK) | 1 | |
| 1341374 | BOLT-SOCKET HEAD (M5X0.8X20-MM) | 1 | |
| 1360155 | SETSCREW (M4X0.7X8-MM) | 1 | |
| 2173383 | 3 BRACKET AS | 1 | |
| 2220365 | 4 CONTROL GP-HANDLE | 2 | |
| 2291203 | 5 COVER | 1 | |
| 1293178 | 6 LOCKNUT (M6X1-THD) | 3 | |
| 5C2890 | 7 NUT (M6X1-THD) | 7 | |
| 5C9553 | 8 BOLT (M6X1X16-MM) | 4 | |
| 5P4115 | 9 WASHER-HARD (7.2X19X2-MM THK) | 3 | |
| 7X0465 | 10 BOLT (M6X1X100-MM) | 3 | |
| 8T4205 | 11 WASHER-HARD (7.2X14.5X2-MM THK) | 11 | |
| 9X2043 | 12 SCREW-TRUSS HEAD (M6X1X14-MM) | 3 |
