System And Components
397-7509 HOOD GP-ENGINES/N LYD1-UP
Group No: 397-7509
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1301916 | 1 STUD-BALL (M8X1.25X20-MM) | 2 | |
| 2506850 | 2 BRACKET AS | 2 | |
| 3587864 | 3 BRACKET AS | 1 | |
| 3617891 | 4 BRACKET AS | 2 | |
| 3717076 | 5 HINGE AS (RH) | 1 | |
| 3717077 | 6 HINGE AS (LH) | 1 | |
| 3724592 | 7 GRILL | 1 | |
| 3912140 | 8 BRACKET | 1 | |
| 3975456 | 9 INSERT AS | 1 | |
| 3977512 | 10 HOOD AS | 1 | |
| 1749194 | 11 BOLT (M8X1.25X16-MM) | 6 | |
| 2089297 | 12 BOLT-FLANGE HEAD (M10X1.5X50-MM) | 2 | |
| 3429920 | 13 BOLT-FLANGE HEAD (M8X1.25X20-MM) | 8 | |
| 5C7261 | 14 NUT (M8X1.25-THD) | 6 | |
| 5P4116 | 15 WASHER-HARD (8.8X20.5X2-MM THK) | 6 | |
| 8T4127 | 16 SCREW-MACHINE (M5X0.8X20-MM) | 6 | |
| 9X6383 | 17 SEAL (28-CM) | ||
| 9X6383 | 17A SEAL (22-CM) | ||
| 2200738 | 18 SEAL (83-CM) |
