397-5422 HOOD & GUARD GPS/N HWC1-UP

Group No: 397-5422
Part NumberPart NameQty
13019161 STUD-BALL (M8X1.25X20-MM)4
15980332 FILM-IDENTIFICATION (12-VOLT)2
16413683 FASTENER (CLIP)2
25068584 LATCH AS1
35147465 FILM-IDENTIFICATION (CAT)1
35742736 HOOD (RH)1
35742747 HOOD (LH)1
35814158 GUARD AS1
9G9155CLIP1
1599540NUT-WELD (M8X1.25-THD)4
36281359 BUMPER AS (RH)1
362813610 BUMPER AS (LH)1
8C8778STUD-WELD (M8X1.25X25-MM)2
363286711 SPRING AS-GAS (HOOD, REAR)2
366922012 MAT1
367005513 PLATE AS1
367776414 PLATE1
368029115 GRILL GP-RADIATOR1
369205316 PLATE AS1
372461417 PLATE1
399834718 CABLE AS1
417424219 SPRING1
417432820 BRACKET AS1
1599540NUT-WELD (M8X1.25-THD)2
418403721 SPRING AS-GAS (HOOD, FRONT)2
420486822 LOCK AS1
424230523 GROMMET1
127217024 SCREW-TRUSS HEAD (M8X1.25X20-MM)12
178333625 NUT-HEX FLANGE (M8X1.25-THD)4
198389926 SCREW-BUTTON HEAD (M8X1.25X20-MM)2
342991327 BOLT-FLANGE HEAD (M10X1.5X20-MM)6
342992028 BOLT-FLANGE HEAD (M8X1.25X20-MM)3
5C726129 NUT (M8X1.25-THD)3
5P411630 WASHER-HARD (8.8X20.5X2-MM THK)9
6V894931 NUT (M10X1.5-THD)2
7X253732 BOLT (M8X1.25X35-MM)2
9G130733 GROMMET1
292289634 CONDUIT (16.9-MM ID)(40-CM)
220073835 SEAL (52-CM EACH)
220073835A SEAL (11-CM EACH)
220073835B SEAL (5-CM EACH)
