System And Components
435-0434 HOOD GP-ENGINES/N HWC1-UP
Group No: 435-0434
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2506850 | 1 BRACKET AS | 2 | |
| 3521908 | 2 HOOD AS | 1 | |
| 3587864 | 3 BRACKET AS | 1 | |
| 3617891 | 4 BRACKET AS | 2 | |
| 3717076 | 5 HINGE AS (RH) | 1 | |
| 3717077 | 6 HINGE AS (LH) | 1 | |
| 1301916 | 7 STUD-BALL (M8X1.25X20-MM) | 2 | |
| 1749194 | 8 BOLT (M8X1.25X16-MM) | 6 | |
| 2089297 | 9 BOLT-FLANGE HEAD (M10X1.5X50-MM) | 2 | |
| 2200738 | 10 SEAL (83-CM) | ||
| 3429920 | 11 BOLT-FLANGE HEAD (M8X1.25X20-MM) | 6 | |
| 3724592 | 12 GRILL | 1 | |
| 5C7261 | 13 NUT (M8X1.25-THD) | 6 | |
| 5P4116 | 14 WASHER-HARD (8.8X20.5X2-MM THK) | 6 | |
| 8T4127 | 15 SCREW-MACHINE (M5X0.8X20-MM) | 6 |
