System And Components
320-5933 FRAME GP-SLIDINGS/N EME1-UP
Group No: 320-5933
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9R0481 | 1 WASHER (71X110X4-MM THK) | 2 | |
| 1617145 | 2 SEAL-PISTON | 4 | |
| 3818054 | 3 CYLINDER GP-SWING | 1 | |
| 3818055 | 4 CYLINDER GP-SWING (LH) | 1 | |
| 3164811 | 5 WASHER (66.5X120X8-MM THK) | 1 | |
| 3202948 | 6 CAP-CYLINDER END | 4 | |
| 3202949 | 7 BAR | 2 | |
| 3203619 | 8 PISTON | 4 | |
| 3203620 | 9 PAD | 2 | |
| 3223768 | 10 CAP & BEARING AS | 1 | |
| 9R4110 | 10A BUSHING | 2 | |
| 3223770 | 11 FRAME AS-SLIDING | 1 | |
| 3311521 | 11A BEARING | 1 | |
| 3311522 | 11B BEARING | 1 | |
| 9R4110 | 11C BUSHING | 2 | |
| 3406272 | 12 RING-WEAR | 8 | |
| 3414712 | 13 BAR | 2 | |
| 1695792 | 14 BOLT (M24X3X160-MM) | 12 | |
| 3B8488 | 15 FITTING-GREASE (1/8-27 PTF) | 2 | |
| 3B8489 | 16 FITTING-GREASE (1/8-27 PTF) | 2 | |
| 3P0439 | 17 SEAL-O-RING | 4 | |
| 7K9208 | 18 SEAL-LIP TYPE | 4 | |
| 8C3347 | 19 PIN-ROLL | 2 | |
| 8T1482 | 20 WASHER-HARD (26X50X8-MM THK) | 6 | |
| 8T4121 | 21 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4167 | 22 WASHER-HARD (26X44X4-MM THK) | 6 | |
| 2135007 | 23 BOLT (M20X2.5X80-MM) | 4 | |
| 8T4648 | 24 BOLT (M12X1.75X70-MM) | 16 | |
| 8T5035 | 25 BOLT (M10X1.5X65-MM) | 4 | |
| 8T5439 | 26 WASHER-HARD (21.5X45X6-MM THK) | 4 | |
| 8T7971 | 27 WASHER-HARD (13.5X25.5X5-MM THK) | 16 | |
| 2984783 | 28 DOWEL | 2 |
