System And Components
378-9623 FRAME GP-SWINGS/N SJL730-UP
Group No: 378-9623
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2U9234 | 1 BUSHING | 1 | |
| 1760626 | 2 WASHER (67.5X120X3-MM THK) | 2 | |
| 9R8291 | 3 SPACER (66X125X1-MM THK) | 2 | |
| 3100851 | 4 PIN | 2 | |
| 3166951 | 5 PIN AS | 1 | |
| 3166952 | 6 PIN AS | 1 | |
| 3260089 | 7 PIN AS | 1 | |
| 3751442 | 8 RING-RETAINING | 1 | |
| 3789622 | 9 FRAME AS-SWING | 1 | |
| 2136702 | 9A BUSHING | 4 | |
| 3311521 | 9B BEARING | 2 | |
| 2705290 | 10 BOLT-SOCKET HEAD (M12X1.75X300-MM) | 1 | |
| 3B8489 | 11 FITTING-GREASE (1/8-27 PTF) | 2 | |
| 5P1076 | 12 WASHER-HARD (13.5X30X4-MM THK) | 2 | |
| 6V7687 | 13 LOCKNUT (M12X1.75-THD) | 1 | |
| 7X0632 | 14 WASHER-HARD (11X36X6-MM THK) | 2 | |
| 8T4136 | 15 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4196 | 16 BOLT (M10X1.5X35-MM) | 1 | |
| 4228652 | 17 GUARD | 1 |
